ADS-4100 scanner ADF scanner
600 x 600 DPI A4 Black, White
Model ADS-4100Part no. ADS4100F5EAN 3234424100054
57 specifications
- Weight3.02 kg
- ColourBlack, White
- Maximum scan size215.9 x 355.6 mm
- Scanner typeADF scanner
- Sensor typeDual CIS
- Auto document feeder (ADF) input capacity60 sheets
Overview
- Weight
- 3.02 kg
- Colour
- Black, White
- Maximum scan size
- 215.9 x 355.6 mm
- Scanner type
- ADF scanner
- Sensor type
- Dual CIS
- Auto document feeder (ADF) input capacity
- 60 sheets
- Brand
- Brother
- Category
- Scanner
- Model
- ADS-4100
- Part numbers
- ADS4100F5, ADS-4100, ADS4100ZU1, ADS4100T
- EAN / UPC
- 3234424100054, 4977766814492, 4977766814515, 4977766814485 +1 more
- Also known as
- Brother ADS-4100 scanner ADF scanner 600 x 600 DPI A4 Black, White
Specifications
57 specifications in 15 groups
Scanning
| Specification | Value |
|---|---|
| Maximum scan size | 215.9 x 355.6 mm |
| Enhanced scan resolution | 1200 x 1200 DPI |
| Optical scanning resolution | 600 x 600 DPI |
| Colour scanning | Yes |
| Duplex scanning | Yes |
| Greyscale levels | 256 |
| ADF scan speed (b/w, A4) | 35 ppm |
| ADF scan speed (colour, A4) | 35 ppm |
| Duplex ADF scan speed (b/w, A4) | 70 ipm |
| Duplex ADF scan speed (colour, A4) | 70 ipm |
Design
| Specification | Value |
|---|---|
| Scanner type | ADF scanner |
| Built-in display | No |
| Product colour | Black, White |
| Control type | Buttons |
Performance
| Specification | Value |
|---|---|
| Sensor type | Dual CIS |
| Scan to | Image, PC, USB |
| Scan drivers | ICA, SANE, WIA |
| Scanning noise level | 59 dB |
Input capacity
| Specification | Value |
|---|---|
| Auto document feeder (ADF) input capacity | 60 sheets |
Paper handling
| Specification | Value |
|---|---|
| Maximum ISO A-series paper size | A4 |
| Scanning media types supported | Business Card, Plain paper, Plastic Card, Recycled paper, Thick paper, Thin paper |
| Card thickness (max) | 1.1 mm |
| Auto Document Feeder (ADF) media weight | 40 - 200 g/m² |
| Maximum scan width | 21.6 cm |
| Maximum scan length | 35.5 cm |
Ports & interfaces
| Specification | Value |
|---|---|
| USB port | Yes |
| USB version | 2.0 |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 23 W |
| Power supply type | AC |
| Power consumption (standby) | 5.4 W |
| Power consumption (off) | 0.1 W |
| Power consumption (sleep) | 1.4 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 243 mm |
| Depth | 320 mm |
| Height | 391 mm |
| Weight | 3.02 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 391 mm |
| Package depth | 320 mm |
| Package height | 243 mm |
| Package weight | 3.7 kg |
Packaging content
| Specification | Value |
|---|---|
| Cables included | AC, USB |
System requirements
| Specification | Value |
|---|---|
| Linux operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Server operating systems supported | Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
| Windows operating systems supported | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 35 °C |
| Operating relative humidity (H-H) | 20 - 80% |
Other features
| Specification | Value |
|---|---|
| Spare part retention | 5 year(s) |
Technical details
| Specification | Value |
|---|---|
| Pallet type | 800 x 1200 mm |
Logistics data
| Specification | Value |
|---|---|
| Products per pallet | 50 pc(s) |
| Country of origin | China |
| Harmonized System (HS) code | 84716070 |
| Layers per pallet | 5 pc(s) |
| Master (outer) cases per pallet | 50 pc(s) |
| Master (outer) cases per pallet layer | 10 pc(s) |
| Pallet gross height | 17.7 cm |
| Pallet gross weight | 202 kg |
