ADS-3100 scanner
600 x 600 DPI A4 Black, White
Model ADS-3100EAN 012502666325
46 specifications
- Memory512 MB
- Weight2.6 kg
- ColourBlack, White
- Maximum scan size355.6 x 215.9 mm
- Built-in displayNo
- Sensor typeDual CIS
Overview
- Memory
- 512 MB
- Weight
- 2.6 kg
- Colour
- Black, White
- Maximum scan size
- 355.6 x 215.9 mm
- Built-in display
- No
- Sensor type
- Dual CIS
- Brand
- Brother
- Category
- Scanner
- Model
- ADS-3100
- Part number
- ADS-3100
- EAN / UPC
- 012502666325, 4977766814539
- Also known as
- Brother ADS-3100 scanner 600 x 600 DPI A4 Black, White
Specifications
46 specifications in 10 groups
Scanning
| Specification | Value |
|---|---|
| Maximum scan size | 355.6 x 215.9 mm |
| Enhanced scan resolution | 1200 x 1200 DPI |
| Optical scanning resolution | 600 x 600 DPI |
| Colour scanning | Yes |
| Duplex scanning | Yes |
| Input colour depth | 48 bit |
| Output colour depth | 24 bit |
| Output greyscale depth | 8 bit |
| ADF scan speed (colour, A4) | 40 ppm |
| Duplex ADF scan speed (colour, A4) | 80 ipm |
Design
| Specification | Value |
|---|---|
| Built-in display | No |
| Product colour | Black, White |
| Control type | Buttons |
Performance
| Specification | Value |
|---|---|
| Sensor type | Dual CIS |
| Scan file formats | JPEG, PDF, TIFF |
| Daily duty cycle (max) | 6000 pages |
| Internal memory | 512 MB |
Input capacity
| Specification | Value |
|---|---|
| Auto document feeder (ADF) input capacity | 60 sheets |
Paper handling
| Specification | Value |
|---|---|
| Maximum ISO A-series paper size | A4 |
| Scanning media types supported | Business Card, Plain paper, Plastic Card, Recycled paper, Thick paper, Thin paper |
| Long-paper mode | Yes |
| Media thickness (min) | 0.08 mm |
| Card thickness (max) | 1.32 mm |
| Paper tray media weight | 40 - 200 g/m² |
| Maximum scan width | 21.6 cm |
| Maximum scan length | 5 m |
Ports & interfaces
| Specification | Value |
|---|---|
| USB port | Yes |
| USB version | 2.0/3.2 Gen 1 (3.1 Gen 1) |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 23 W |
| Power supply type | AC |
| Power consumption (standby) | 5.4 W |
| Power consumption (off) | 0.1 W |
| AC input frequency | 50 - 60 Hz |
| Input voltage | 100-240 V |
| Power consumption (sleep) | 1.4 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 299 mm |
| Depth | 215 mm |
| Height | 190 mm |
| Weight | 2.6 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 391 mm |
| Package depth | 215 mm |
| Package height | 320 mm |
| Package weight | 3.31 kg |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 35 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 10 - 90% |
