Brother ADS-3000N scanner ADF scanner

600 x 600 DPI A4 Black

Model ADS-3000NEAN 4977766755245

67 specifications

Memory256 MB
Weight5.05 kg
ColourBlack
Maximum scan size215.9 x 355 mm
Scanner typeADF scanner
Sensor typeDual CIS

See all specifications

Overview

Memory: 256 MB
Weight: 5.05 kg
Colour: Black
Maximum scan size: 215.9 x 355 mm
Scanner type: ADF scanner
Sensor type: Dual CIS

Brand: Brother
Category: Scanner
Model: ADS-3000N
Part number: ADS-3000N
EAN / UPC: 4977766755245, 012502642763, 4977766755238, 4977766755252 +1 more
Also known as: Brother ADS-3000N scanner ADF scanner 600 x 600 DPI A4 Black

Specifications

67 specifications in 17 groups

Scanning

Specification	Value
Maximum scan size	215.9 x 355 mm
Enhanced scan resolution	1200 x 1200 DPI
Optical scanning resolution	600 x 600 DPI
Colour scanning	Yes
Duplex scanning	Yes
Input colour depth	30 bit
Output colour depth	24 bit
Film scanning	No
ADF scan speed (b/w, A4)	50 ppm
ADF scan speed (colour, A4)	50 ppm
Duplex ADF scan speed (b/w, A4)	100 ipm
Duplex ADF scan speed (colour, A4)	100 ipm

Design

Specification	Value
Scanner type	ADF scanner
Built-in display	No
Product colour	Black

Performance

Specification	Value
Sensor type	Dual CIS
Daily duty cycle (max)	5000 pages
Scan to	FTP, File, HTTP, Image, OCR, USB
Scan drivers	ICA, ISIS, TWAIN, WIA
Scanning noise level	63.9 dB
Internal memory	256 MB
Built-in processor	Cortex-A9
Processor frequency	800 MHz

Input capacity

Specification	Value
Auto document feeder (ADF) input capacity	50 sheets

Paper handling

Specification	Value
Maximum ISO A-series paper size	A4
Scanning media types supported	Business Card, Envelopes, Plastic Card
ISO A-series sizes (A0...A9)	A4, A5, A6, A7, A8
ISO B-series sizes (B0...B9)	B5, B6, B7, B8
Legal	Yes
Letter	Yes
Auto Document Feeder (ADF) media weight	27 - 413 g/m²

Ports & interfaces

Specification	Value
USB port	Yes
USB version	3.2 Gen 1 (3.1 Gen 1)
Standard interfaces	Ethernet, USB 3.2 Gen 1 (3.1 Gen 1)

Network

Specification	Value
Ethernet LAN	Yes
Supported network protocols	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, Custom Raw Port/Port9100, SMTP Client, FTP Client and Server, LDAP Client, CIFS Client, SNMPv1/v2c/v3, HTTP/HTTPS server, TFTP client and server, ICMP, Web Services (Scan), SNTP Client

Power

Specification	Value
Power consumption (typical)	30 W
Power supply type	AC
Power consumption (standby)	4.1 W
Power consumption (off)	0.12 W
Power consumption (PowerSave)	2.9 W

Weight & dimensions

Specification	Value
Width	255 mm
Depth	355 mm
Height	380 mm
Weight	5.05 kg

Packaging data

Specification	Value
Package width	382 mm
Package depth	254 mm
Package height	330 mm
Package weight	6.1 kg

Packaging content

Specification	Value
Drivers included	Yes

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR

System requirements

Specification	Value
Linux operating systems supported	Yes
Mac operating systems supported	Yes
Windows operating systems supported	Yes

Operational conditions

Specification	Value
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80%

Other features

Specification	Value
Spare part retention	5 year(s)

Technical details

Specification	Value
PC connection	RJ-45
Pallet type	800 x 1200 mm

Logistics data

Specification	Value
Products per pallet	36 pc(s)
Country of origin	China
Harmonized System (HS) code	84716070
Layers per pallet	4 pc(s)
Master (outer) cases per pallet	36 pc(s)
Master (outer) cases per pallet layer	9 pc(s)
Pallet gross height	14.5 cm
Pallet gross weight	212.4 kg
