Brother ADS-2600We ADF scanner

600 x 600 DPI A4 Black

Model ADS-2600WePart no. ADS-2600WEEAN 8062015022417

74 specifications

Display9.4 cm (3.7")
Memory256 MB
Weight4.05 kg
ColourBlack
Maximum scan size215.9 x 355.6 mm
Scanner typeADF scanner

See all specifications

Overview

Display: 9.4 cm (3.7")
Memory: 256 MB
Weight: 4.05 kg
Colour: Black
Maximum scan size: 215.9 x 355.6 mm
Scanner type: ADF scanner

Brand: Brother
Category: Scanner
Model: ADS-2600We
Part number: ADS-2600WE
EAN / UPC: 8062015022417, 092015022511, 1032015024206, 1112015022256 +15 more
Also known as: Brother ADS-2600We ADF scanner 600 x 600 DPI A4 Black

Specifications

74 specifications in 16 groups

Scanning

Specification	Value
Maximum scan size	215.9 x 355.6 mm
Enhanced scan resolution	1200 x 1200 DPI
Optical scanning resolution	600 x 600 DPI
Colour scanning	Yes
Duplex scanning	Yes
Input colour depth	30 bit
Output colour depth	24 bit
Greyscale levels	256
ADF scan speed (b/w, A4)	24 ppm
ADF scan speed (colour, A4)	24 ppm
Duplex ADF scan speed (b/w, A4)	24 ipm
Duplex ADF scan speed (colour, A4)	24 ipm
Black/white scanning colour modes	Grayscale, Monochrome

Design

Specification	Value
Scanner type	ADF scanner
Built-in display	Yes
Product colour	Black
Display diagonal	9.4 cm (3.7")
Touchscreen	Yes

Performance

Specification	Value
Sensor type	CMOS dual CIS
Scan file formats	JPG, PDF, TIFF
Maximum duty cycle	1500 pages per month
Scan to	Cloud, E-mail, E-mail Server, File, FTP, Image, OCR, USB
Scan drivers	ICA, ISIS, SANE, TWAIN, WIA
Scanning noise level	62.5 dB
Internal memory	256 MB
Built-in processor	Star Sapphire
Processor frequency	400 MHz

Input capacity

Specification	Value
Standard input capacity	50 sheets

Paper handling

Specification	Value
Maximum ISO A-series paper size	A4
Scanning media types supported	Business Card, Plain paper, Plastic Card, Recycled paper, Thick paper, Thin paper
Multi feed detection	Yes
ISO A-series sizes (A0...A9)	A4, A5, A6, A8
ISO B-series sizes (B0...B9)	B5, B6, B8
Legal	Yes
Letter	Yes
Auto Document Feeder (ADF) media weight	52 - 110 g/m²

Ports & interfaces

Specification	Value
USB port	Yes
USB version	2.0
Standard interfaces	Ethernet, USB 1.1, USB 2.0, Wireless LAN

Network

Specification	Value
Wi-Fi	Yes
Ethernet LAN	Yes
Security algorithms	802.1x RADIUS, APOP, EAP, EAP-FAST, EAP-MD5, EAP-TLS, EAP-TTLS, HTTPS, PEAP, SMTP-AUTH, SSL/TLS
Mobile printing technologies	Brother iPrint & Scan
Supported network protocols	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS, DNS, mDNS, LLMNR, Custom Raw Port/Port9100, SMTP Client, FTP Client/Server, LDAP Client, CIFS Client, SNMPv1/v2c/v3, HTTP/HTTPS server, TFTP client/server, ICMP, Web Services, SNTP Client

Power

Specification	Value
Power consumption (typical)	20 W
Power supply type	AC
Power consumption (standby)	4 W
Power consumption (off)	0.3 W
AC input frequency	50 - 60 Hz
Power consumption (PowerSave)	2 W
Input voltage	220-240 V

Weight & dimensions

Specification	Value
Width	380 mm
Depth	280 mm
Height	290 mm
Weight	4.05 kg

Packaging data

Specification	Value
Package width	383 mm
Package depth	291 mm
Package height	285 mm
Package weight	5 kg

Packaging content

Specification	Value
Cables included	AC, USB
Quick start guide	Yes
Drivers included	Yes
Bundled software	Nuance PDF Converter Professional 8 Nuance PaperPort 12 SE PageManager 9 NewSoft Presto! BizCard 6 Brother Control Center 4

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR

System requirements

Specification	Value
Linux operating systems supported	Yes
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Win

Operational conditions

Specification	Value
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80%

Other features

Specification	Value
Network ready	Yes
Ethernet LAN data rates	10,100 Mbit/s
Custom media length	70 - 863 mm
Custom media width	51 - 215.9 mm

Logistics data

Specification	Value
Country of origin	China
