Brother ADS-2200 scanner ADF scanner
600 x 600 DPI A4 Black, White
Model ADS-2200EAN 4977766776677
67 specifications
- Memory512 MB
- Weight2.94 kg
- ColourBlack, White
- Maximum scan size215.9 x 355.6 mm
- Scanner typeADF scanner
- Sensor typeDual CIS
Overview
- Memory
- 512 MB
- Weight
- 2.94 kg
- Colour
- Black, White
- Maximum scan size
- 215.9 x 355.6 mm
- Scanner type
- ADF scanner
- Sensor type
- Dual CIS
- Brand
- Brother
- Category
- Scanner
- Model
- ADS-2200
- Part number
- ADS-2200
- EAN / UPC
- 4977766776677, 012502648710, 4002352011112, 4977766776684 +1 more
- Also known as
- Brother ADS-2200 scanner ADF scanner 600 x 600 DPI A4 Black, White
Specifications
67 specifications in 15 groups
Scanning
| Specification | Value |
|---|---|
| Maximum scan size | 215.9 x 355.6 mm |
| Enhanced scan resolution | 1200 x 1200 DPI |
| Optical scanning resolution | 600 x 600 DPI |
| Colour scanning | Yes |
| Duplex scanning | Yes |
| Input colour depth | 48 bit |
| Output greyscale depth | 8 bit |
| Film scanning | No |
| Greyscale levels | 256 |
| ADF scan speed (b/w, A4) | 35 ppm |
| ADF scan speed (colour, A4) | 35 ppm |
Design
| Specification | Value |
|---|---|
| Scanner type | ADF scanner |
| Built-in display | No |
| Product colour | Black, White |
Performance
| Specification | Value |
|---|---|
| Sensor type | Dual CIS |
| Light source | LED |
| Scan file formats | JPG, PDF, TIFF |
| Daily duty cycle (max) | 3000 pages |
| Scan to | E-mail, File, Image, OCR, USB |
| Scan drivers | ICA, SANE, TWAIN, WIA |
| Scanning noise level | 62 dB |
| Internal memory | 512 MB |
Input capacity
| Specification | Value |
|---|---|
| Auto document feeder (ADF) input capacity | 50 sheets |
Paper handling
| Specification | Value |
|---|---|
| Maximum ISO A-series paper size | A4 |
| Scanning media types supported | Plain paper, Recycled paper, Thick paper, Thin paper |
| Long-paper mode | Yes |
| ISO A-series sizes (A0...A9) | A4, A5, A6 |
| ISO B-series sizes (B0...B9) | B5, B6 |
| Legal | Yes |
| Letter | Yes |
| Auto Document Feeder (ADF) media weight | 50 - 209 g/m² |
| Maximum scan width | 21.6 cm |
| Maximum scan length | 5 m |
Ports & interfaces
| Specification | Value |
|---|---|
| USB port | Yes |
| USB version | 2.0 |
| Standard interfaces | USB 2.0 |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 21 W |
| Power supply type | AC |
| Power consumption (standby) | 4.7 W |
| Power consumption (off) | 0.1 W |
| AC input frequency | 50 - 60 Hz |
| Input voltage | 100-240 V |
| Power consumption (sleep) | 0.8 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 250 mm |
| Depth | 290 mm |
| Height | 390 mm |
| Weight | 2.94 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 393 mm |
| Package depth | 245 mm |
| Package height | 286 mm |
| Package weight | 3.86 kg |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Cables included | AC |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 35 °C |
| Storage temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 20 - 80% |
Other features
| Specification | Value |
|---|---|
| Spare part retention | 5 year(s) |
Technical details
| Specification | Value |
|---|---|
| Pallet type | 800 x 1200 mm |
Logistics data
| Specification | Value |
|---|---|
| Products per pallet | 40 pc(s) |
| Country of origin | China |
| Harmonized System (HS) code | 84716070 |
| Layers per pallet | 5 pc(s) |
| Master (outer) cases per pallet | 40 pc(s) |
| Master (outer) cases per pallet layer | 8 pc(s) |
| Pallet gross height | 15.7 cm |
| Pallet gross weight | 146 kg |
Energy efficiency
ENERGY STAR certified
Imaging equipment · model ADS-2200 · certified Jul 31, 2019 · United States
| Measurement | Value |
|---|---|
| Sleep-mode power | 0.53 W |
| Standby power | 0.04 W |
