PLA5405 v2
Model PLA5405 v2Part no. PLA5405V2-EU0201FEAN 4718937598465
26 specifications
- Speed1200 Mbit/s
- ColourWhite
- Power consumption (typical)4 W
- LED indicatorsYes
- Operating temperature (T-T)0 - 40 °C
- Width90 mm
Overview
- Speed
- 1200 Mbit/s
- Colour
- White
- Power consumption (typical)
- 4 W
- LED indicators
- Yes
- Operating temperature (T-T)
- 0 - 40 °C
- Width
- 90 mm
- Brand
- Zyxel
- Category
- PowerLine Network Adapter
- Model
- PLA5405 v2
- Part numbers
- PLA5405V2-EU0201F, PLA5405V2-GB0201F
- EAN / UPC
- 4718937598465
- Also known as
- Zyxel PLA5405 v2 1200 Mbit/s Ethernet LAN White 2 pc(s)
Specifications
26 specifications in 6 groups
Performance
| Specification | Value |
|---|---|
| Maximum data transfer rate | 1200 Mbit/s |
| Ethernet LAN | Yes |
| Ethernet LAN interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet LAN (RJ-45) ports | 1 |
| Wi-Fi | No |
| PowerLine standard | HomePlug AV2 |
| Security algorithms | 128-bit AES |
| Maximum operating distance | 300 m |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 4 W |
| Power consumption (standby) | 0.5 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
Design
| Specification | Value |
|---|---|
| LED indicators | Yes |
| Product colour | White |
| Certification | CE, FCC, BSMI CE-LVD, IEC |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -30 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 10 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 90 mm |
| Depth | 60 mm |
| Height | 27 mm |
Packaging content
| Specification | Value |
|---|---|
| Quantity per pack | 2 pc(s) |
| Quick installation guide | Yes |
| Cables included | LAN (RJ-45) |
