TL-PA4022P KIT
Model TL-PA4022P KITPart no. TL-PA4022P KIT (UK)EAN 6935364070274
28 specifications
- Speed600 Mbit/s
- ColourWhite
- LED indicatorsYes
- Operating temperature (T-T)0 - 40 °C
- Width42 mm
Overview
- Speed
- 600 Mbit/s
- Colour
- White
- LED indicators
- Yes
- Operating temperature (T-T)
- 0 - 40 °C
- Width
- 42 mm
- Brand
- TP-Link
- Category
- PowerLine Network Adapter
- Model
- TL-PA4022P KIT
- Part numbers
- TL-PA4022P KIT (UK), TL-PA4022P KIT
- EAN / UPC
- 6935364070274, 6935364084028
- Also known as
- TP-Link AV600 2-port Passthrough Powerline Starter Kit
Specifications
28 specifications in 6 groups
Performance
| Specification | Value |
|---|---|
| Maximum data transfer rate | 600 Mbit/s |
| Ethernet LAN | Yes |
| Ethernet LAN interface type | Fast Ethernet |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Ethernet LAN (RJ-45) ports | 3 |
| Wi-Fi | No |
| Networking standards | IEEE 802.3, IEEE 802.3u |
| Built-in power socket | Yes |
| PowerLine standard | HomePlug AV |
| Modulation | OFDM |
| Security algorithms | 128-bit AES |
| Encryption button | Yes |
| Plug and Play | Yes |
| Compatible products | CE, RoHS |
Design
| Specification | Value |
|---|---|
| LED indicators | Yes |
| Product colour | White |
| Certification | CE |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Mac operating systems supported | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 42 mm |
| Depth | 58 mm |
| Height | 95 mm |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
