FRITZ!Powerline 1260
Model FRITZ!Powerline 1260Part no. 20002789EAN 4023125027895
33 specifications
- Speed1200 Mbit/s
- Weight200 g
- ColourWhite
- AC input voltage230 V
- LED indicatorsLAN, Power
- Width67 mm
Overview
- Speed
- 1200 Mbit/s
- Weight
- 200 g
- Colour
- White
- AC input voltage
- 230 V
- LED indicators
- LAN, Power
- Width
- 67 mm
- Brand
- FRITZ!
- Category
- PowerLine Network Adapter
- Model
- FRITZ!Powerline 1260
- Part number
- 20002789
- EAN / UPC
- 4023125027895
- Also known as
- Powerline FRITZ! 1260 1200 Mbit/s Ethernet LAN Wi-Fi White 1 pc(s)
Specifications
33 specifications in 7 groups
Performance
| Specification | Value |
|---|---|
| Maximum data transfer rate | 1200 Mbit/s |
| Ethernet LAN | Yes |
| Ethernet LAN interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-T, 1000BASE-T |
| Ethernet LAN (RJ-45) ports | 1 |
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi standards | 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| WLAN data transfer rates supported | 11,54,150,300,866 Mbit/s |
| Networking standards | IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i |
| Power plug | Type F |
| Built-in power socket | Yes |
| PowerLine standard | HomePlug AV2 |
| Security algorithms | 128-bit AES |
| Frequency range | 2400 - 5000 MHz |
Power
| Specification | Value |
|---|---|
| AC input voltage | 230 V |
| AC input frequency | 50 Hz |
Design
| Specification | Value |
|---|---|
| LED indicators | LAN, Power |
| Product colour | White |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 10, Windows 7, Windows 8, Windows Vista, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 67 mm |
| Depth | 32 mm |
| Height | 132 mm |
| Weight | 200 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 127 mm |
| Package depth | 192 mm |
| Package height | 88 mm |
| Package weight | 440 g |
| Package type | Box |
Packaging content
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Quick installation guide | Yes |
| Cables included | LAN (RJ-45) |
