DHP-509AV PowerLine network adapter 500 Mbit/s Ethernet LAN White 2 pc(s)
Model DHP-509AVPart no. DHP-509AV/BEAN 7426043660682
22 specifications
- Speed500 Mbit/s
- ColourWhite
- AC input voltage100-240 V
- LED indicatorsLAN, Power
- Operating temperature (T-T)0 - 40 °C
- Width70 mm
Overview
- Speed
- 500 Mbit/s
- Colour
- White
- AC input voltage
- 100-240 V
- LED indicators
- LAN, Power
- Operating temperature (T-T)
- 0 - 40 °C
- Width
- 70 mm
- Brand
- D-Link
- Category
- PowerLine Network Adapter
- Model
- DHP-509AV
- Part numbers
- DHP-509AV/B, DHP-509AV, DHP-509AV/E
- EAN / UPC
- 7426043660682, 790069414817, 4056203447322, 790069416347 +1 more
- Also known as
- D-Link DHP-509AV PowerLine network adapter 500 Mbit/s Ethernet LAN White 2 pc(s)
Specifications
22 specifications in 6 groups
Performance
| Specification | Value |
|---|---|
| Maximum data transfer rate | 500 Mbit/s |
| Ethernet LAN | Yes |
| Ethernet LAN interface type | Fast Ethernet |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Ethernet LAN (RJ-45) ports | 1 |
| Wi-Fi | No |
| Networking standards | IEEE 802.3, IEEE 802.3u |
| Built-in power socket | No |
| PowerLine standard | HomePlug AV |
| Modulation | OFDM |
| Security algorithms | 128-bit AES |
Power
| Specification | Value |
|---|---|
| AC input voltage | 100-240 V |
| AC input frequency | 50 - 60 Hz |
Design
| Specification | Value |
|---|---|
| LED indicators | LAN, Power |
| Product colour | White |
| Certification | CE LVD, FCC, UL |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 70 mm |
| Depth | 52 mm |
| Height | 26 mm |
Packaging content
| Specification | Value |
|---|---|
| Quantity per pack | 2 pc(s) |
