CLUB3D CSP-D700CB power supply unit
700 W 20+4 pin ATX ATX Black, Green
Model CSP-D700CBEAN 8717249408703
49 specifications
- Noise10 dB
- ColourBlack, Green
- Total power700 W
- Motherboard power connector20+4 pin ATX
- PurposePC
- Width150 mm
Overview
- Noise
- 10 dB
- Colour
- Black, Green
- Total power
- 700 W
- Motherboard power connector
- 20+4 pin ATX
- Purpose
- PC
- Width
- 150 mm
- Brand
- CLUB3D
- Category
- Power Supply Unit
- Model
- CSP-D700CB
- Part number
- CSP-D700CB
- EAN / UPC
- 8717249408703
- Also known as
- CLUB3D CSP-D700CB power supply unit 700 W 20+4 pin ATX ATX Black, Green
Specifications
49 specifications in 9 groups
Power
| Specification | Value |
|---|---|
| Total power | 700 W |
| AC input voltage | 115 - 230 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 15 A |
| Combined power (+3.3V) | 170 W |
| Combined power (+12V) | 679 W |
| Combined power (+5V) | 170 W |
| Combined power (-12V) | 6 W |
| Combined power (+5Vsb) | 15 W |
| Max output current (+3.3V) | 24 A |
| Max output current (+12V1) | 32 A |
| Max output current (+12V2) | 32 A |
| Max output current (+12V3) | 32 A |
| Max output current (+12V4) | 32 A |
| Max output current (+5V) | 30 A |
| Max output current (-12V) | 0.5 A |
| Max output current (+5Vsb) | 3 A |
| Efficiency | 89% |
| Power protection features | Over current, Over power, Over voltage, Short circuit, Under voltage |
Ports & interfaces
| Specification | Value |
|---|---|
| Motherboard power connector | 20+4 pin ATX |
| Number of SATA power connectors | 6 |
| Peripheral (Molex) power connectors (4-pin) | 5 |
| PCI Express power connectors (6-pin) | 2 |
| PCI Express power connectors (8-pin) | 2 |
| CPU power connector (4+4 pin) | Yes |
| ATX power connector (20+4 pin) | Yes |
| Floppy disk drive connector | Yes |
| Floppy drive power connector | 1 |
| PCI Express connector | Yes |
| Cabling type | Semi-Modular |
Performance
| Specification | Value |
|---|---|
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| 80 PLUS certification | 80 PLUS Bronze |
| ATX version | 2.4 |
| Noise level | 10 dB |
Design
| Specification | Value |
|---|---|
| Product colour | Black, Green |
| Cooling type | Active |
| Fan diameter | 13.5 cm |
| Number of fans | 1 fan(s) |
| On/off switch | Yes |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
| Certification | CE, 80Plus |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 150 mm |
| Depth | 165 mm |
| Height | 86 mm |
Packaging data
| Specification | Value |
|---|---|
| Manual | Yes |
Technical details
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
Other features
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 150 x 165 x 86 mm |
| Power supply type | AC/DC |
