APC PDUM160H-B power distribution unit (PDU)
Model PDUM160H-BEAN 731304257608
18 specifications
- Weight411.8 kg
- Input connection typeHard Wire 5-wire (3PH + N + G)
- Nominal input voltage400 V
- Operating temperature (T-T)0 - 40 °C
- Width600 mm
Overview
- Weight
- 411.8 kg
- Input connection type
- Hard Wire 5-wire (3PH + N + G)
- Nominal input voltage
- 400 V
- Operating temperature (T-T)
- 0 - 40 °C
- Width
- 600 mm
- Brand
- APC
- Category
- Power Distribution Units (PDUs)
- Model
- PDUM160H-B
- Part number
- PDUM160H-B
- EAN / UPC
- 731304257608
- Also known as
- APC PDUM160H-B power distribution unit (PDU)
Specifications
18 specifications in 6 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Input connection type | Hard Wire 5-wire (3PH + N + G) |
| Output connections | 2x Hard Wire 5-wire (3PH + N + G) |
Power
| Specification | Value |
|---|---|
| Nominal input voltage | 400 V |
| Load capacity | 160000 VA |
| Maximum input current per phase | 295 A |
Certificates
| Specification | Value |
|---|---|
| Certification | CE, FCC 15 A |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -15 - 40 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 600 mm |
| Depth | 1070 mm |
| Height | 1991 mm |
| Weight | 411.8 kg |
Packaging data
| Specification | Value |
|---|---|
| Package weight | 444.6 kg |
| Package width | 848 mm |
| Package depth | 1210 mm |
| Package height | 2150 mm |
