Product comparison · 2 power distribution units (pdus)

APC PDUM160H-B power distribution unit (PDU) vs Lindy 1U 8 Way IEC Sockets, Horizontal PDU with UK Mains Plug

3specifications compared
3differ
0identical
29known for one product only

Key differences

Nominal input voltage
- PDUM160H-B power distribution unit (PDU):400 V
- 1U 8 Way IEC Sockets, Horizontal PDU with UK Mains Plug:250 V
Certification
- PDUM160H-B power distribution unit (PDU):CE, FCC 15 A
- 1U 8 Way IEC Sockets, Horizontal PDU with UK Mains Plug:BS5733
Height
- PDUM160H-B power distribution unit (PDU):1991 mm
- 1U 8 Way IEC Sockets, Horizontal PDU with UK Mains Plug:44.4 mm

Side by side

Differences highlightedShow differences only

Comparison of PDUM160H-B, 29990
32 specifications	A APC PDUM160H-B power distribution unit (PDU) Model PDUM160H-B View product	B Lindy 1U 8 Way IEC Sockets, Horizontal PDU with UK Mains Plug Model 29990 View product
Ports & interfacesidentical
Input connection typeKnown for one	Hard Wire 5-wire (3PH + N + G)	Unknown — not stated by the source
Output connectionsKnown for one	2x Hard Wire 5-wire (3PH + N + G)	Unknown — not stated by the source
AC outlets quantityKnown for one	Unknown — not stated by the source	8 AC outlet(s)
Power1 differ
Nominal input voltageDiffers	400 V	250 V
Load capacityKnown for one	160000 VA	Unknown — not stated by the source
Maximum input current per phaseKnown for one	295 A	Unknown — not stated by the source
AC input frequencyKnown for one	Unknown — not stated by the source	50 - 60 Hz
Maximum currentKnown for one	Unknown — not stated by the source	13 A
Maximum powerKnown for one	Unknown — not stated by the source	3250 W
Surge protectionKnown for one	Unknown — not stated by the source	Yes
Certificates1 differ
CertificationDiffers	CE, FCC 15 A	BS5733
Operational conditionsidentical
Operating temperature (T-T)Known for one	0 - 40 °C	Unknown — not stated by the source
Storage temperature (T-T)Known for one	-15 - 40 °C	Unknown — not stated by the source
Operating relative humidity (H-H)Known for one	0 - 95%	Unknown — not stated by the source
Storage relative humidity (H-H)Known for one	0 - 95%	Unknown — not stated by the source
Weight & dimensions1 differ
WidthKnown for one	600 mm	Unknown — not stated by the source
DepthKnown for one	1070 mm	Unknown — not stated by the source
HeightDiffers	1991 mm	44.4 mm
WeightKnown for one	411.8 kg	Unknown — not stated by the source
Packaging dataidentical
Package weightKnown for one	444.6 kg	Unknown — not stated by the source
Package widthKnown for one	848 mm	Unknown — not stated by the source
Package depthKnown for one	1210 mm	Unknown — not stated by the source
Package heightKnown for one	2150 mm	Unknown — not stated by the source
Designidentical
TypeKnown for one	Unknown — not stated by the source	Three-phase
Rack capacityKnown for one	Unknown — not stated by the source	1U
MountingKnown for one	Unknown — not stated by the source	Horizontal
Product colourKnown for one	Unknown — not stated by the source	Black
On/off switchKnown for one	Unknown — not stated by the source	Yes
Featuresidentical
LED indicatorsKnown for one	Unknown — not stated by the source	Power
Cable lengthKnown for one	Unknown — not stated by the source	3 m
Management featuresidentical
Management platformKnown for one	Unknown — not stated by the source	IEC
Packaging contentidentical
ManualKnown for one	Unknown — not stated by the source	Yes

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
