APC AP8661 power distribution unit (PDU) 24 AC outlet(s) 0U Black

APC AP8661 power distribution unit (PDU) 24 AC outlet(s) 0U Black

Model AP8661EAN 014475593837

27 specifications

Weight7.14 kg
ColourBlack
PDU typesSwitched
AC outlets quantity24 AC outlet(s)
Cable length3 m
Nominal input voltage208 V

See all specifications

Overview

Weight: 7.14 kg
Colour: Black
PDU types: Switched
AC outlets quantity: 24 AC outlet(s)
Cable length: 3 m
Nominal input voltage: 208 V

Brand: APC
Category: Power Distribution Units (PDUs)
Model: AP8661
Part number: AP8661
EAN / UPC: 014475593837, 731304276999, 809392594698, 7313042769990
Also known as: APC AP8661 power distribution unit (PDU) 24 AC outlet(s) 0U Black

Specifications

27 specifications in 9 groups

Design

Specification	Value
PDU types	Switched
Rack capacity	0U
Product colour	Black

Ports & interfaces

Specification	Value
AC outlets quantity	24 AC outlet(s)
Power plug	NEMA L21-20P

Features

Specification	Value
Cable length	3 m

Power

Specification	Value
Nominal input voltage	208 V
AC input frequency	50 - 60 Hz
Maximum current	20 A
Nominal output voltage	208 V

Certificates

Specification	Value
Compliance certificates	RoHS
Certification	cUL,FCC Part 15 A,ICES-003,UL,VCCI A

Operational conditions

Specification	Value
Operating temperature (T-T)	-5 - 45 °C
Storage temperature (T-T)	-25 - 65 °C
Operating relative humidity (H-H)	5 - 95%
Storage relative humidity (H-H)	5 - 95%
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 15000 m

Weight & dimensions

Specification	Value
Width	56 mm
Depth	51 mm
Height	1829 mm
Weight	7.14 kg

Packaging data

Specification	Value
Package weight	9.41 kg
Package width	162 mm
Package depth	118 mm
Package height	2038 mm

Logistics data

Specification	Value
Total carbon footprint (kg of CO2e)	8613.71
