Viewsonic VOT125B_7HUS_02 PC Intel® Celeron® SU2300

2 GB DDR2-SDRAM 250 GB Windows 7 Home Premium Small Desktop Mini PC Black

Model VOT125B_7HUS_02EAN 766907448313

106 specifications

ProcessorIntel® Celeron®
Memory2 GB
Storage250 GB
TypeMini PC
OSWindows 7 Home Premium
Weight550 g

See all specifications

Overview

Processor: Intel® Celeron®
Memory: 2 GB
Storage: 250 GB
Type: Mini PC
OS: Windows 7 Home Premium
Weight: 550 g

Brand: Viewsonic
Category: PCs/Workstations
Model: VOT125B_7HUS_02
Part number: VOT125B_7HUS_02
EAN / UPC: 766907448313
Also known as: Viewsonic VOT125B_7HUS_02 PC Intel® Celeron® SU2300 2 GB DDR2-SDRAM 250 GB Windows 7 Home Premium Small Desktop Mini PC Black

Specifications

106 specifications in 16 groups

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Celeron®
Processor model	SU2300
Processor cores	2
Processor threads	2
Processor frequency	1.2 GHz
Processor cache	1 MB
Processor cache type	L2
Processor front side bus	800 MHz
Bus type	FSB
FSB Parity	Yes
Processor lithography	45 nm
Processor operating modes	64-bit
Processor series	Intel Celeron Processor SU2000 Series for Mobile
Processor codename	Penryn
Thermal Design Power (TDP)	10 W
Tjunction	100 °C
Number of processors installed	1
Processor socket	BGA 956
Number of Processing Die Transistors	410 M
Processing Die size	107 mm²
Maximum number of SMP processors	1
Platform	PC
Stepping	R0
ECC supported by processor	No

Memory

Specification	Value
Internal memory	2 GB
Internal memory type	DDR2-SDRAM
Memory clock speed	800 MHz

Storage

Specification	Value
Total storage capacity	250 GB
Optical drive type	No
Number of HDDs installed	1
HDD interface	SATA
HDD speed	5400 RPM
Card reader integrated	Yes
Compatible memory cards	Memory Stick (MS), MMC, SD

Performance

Specification	Value
Product type	Mini PC
Motherboard chipset	Intel® GS40 Express

Network

Specification	Value
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Wi-Fi	Yes
Wake-on-LAN ready	Yes
Networking features	Gigabit Ethernet

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
HDMI ports quantity	1
Ethernet LAN (RJ-45) ports	1
Headphone outputs	1
Microphone in	Yes
VGA (D-Sub) ports quantity	0
DVI port	Yes
PS/2 ports quantity	0
Firewire (IEEE 1394) ports	0
DC-in jack	Yes
Serial ports quantity	0
Parallel ports quantity	0

Power

Specification	Value
Power supply type	AC/DC
Power supply	65 W

Design

Specification	Value
Chassis type	Small Desktop
Product colour	Black

Software

Specification	Value
Operating system installed	Windows 7 Home Premium

Display

Specification	Value
Display included	No

Processor special features

Specification	Value
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	No
Intel 64	Yes
Intel Clear Video Technology	No
Intel Demand Based Switching	No
Intel Dual Display Capable Technology	No
Intel Enhanced Halt State	No
Intel FDI Technology	No
Intel Fast Memory Access	No
Intel Flex Memory Access	No
Intel Rapid Storage Technology	No
Intel Trusted Execution Technology	No
Intel VT-x with Extended Page Tables (EPT)	No
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® Wireless Display (Intel® WiDi)	No
Processor ARK ID	42779
Processor code	SLGSB
Processor package size	22 x 22 mm
Thermal Monitoring Technologies	Yes
Intel® Turbo Boost Technology	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® Quick Sync Video Technology	No
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Anti-Theft Technology (Intel® AT)	No
Conflict-Free processor	No

Audio

Specification	Value
Audio system	HD

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 90%
Operating altitude	0 - 3048 m

Weight & dimensions

Specification	Value
Width	39 mm
Depth	115 mm
Height	130 mm
Weight	550 g

Packaging data

Specification	Value
Package dimensions (WxDxH)	267 x 138 x 222 mm
Package weight	1.72 kg

Certificates

Specification	Value
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Certification	FCC, UL, cUL
