MAG Codex X5 12th
Model MAG Codex X5 12thPart no. 9S6-B93071-1092EAN 4719072944827
76 specifications
- ProcessorIntel® Core™ i9
- Memory32 GB
- GraphicsNVIDIA GeForce RTX 3090
- SpeedWi-Fi 6E (802.11ax)
- TypePC
- OSFreeDOS
Overview
- Processor
- Intel® Core™ i9
- Memory
- 32 GB
- Graphics
- NVIDIA GeForce RTX 3090
- Speed
- Wi-Fi 6E (802.11ax)
- Type
- PC
- OS
- FreeDOS
- Brand
- MSI
- Category
- PCs/Workstations
- Model
- MAG Codex X5 12th
- Part number
- 9S6-B93071-1092
- EAN / UPC
- 4719072944827
- Also known as
- MSI MAG Codex X5 12th Intel® Core™ i9 i9-12900K 32 GB DDR5-SDRAM SSD NVIDIA GeForce RTX 3090 FreeDOS Desktop PC Black
Specifications
76 specifications in 15 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Core™ i9 |
| Processor generation | 12th gen Intel® Core™ i9 |
| Processor model | i9-12900K |
| Processor cores | 8 |
| Processor boost frequency | 5.2 GHz |
| Processor frequency | 3.2 GHz |
| Processor cache | 30 MB |
| Processor cache type | Smart Cache |
| Bus type | DMI4 |
Memory
| Specification | Value |
|---|---|
| Internal memory | 32 GB |
| Maximum internal memory | 128 GB |
| Internal memory type | DDR5-SDRAM |
| Memory layout (slots x size) | 1 x 32 GB |
| Memory slots | 4x DIMM |
| Memory clock speed | 4400 MHz |
Storage
| Specification | Value |
|---|---|
| Optical drive type | No |
| Storage media | SSD |
| HDD speed | 7200 RPM |
| HDD size | 3.5" |
| SSD interface | M.2, PCI Express 3.0, PCI Express 4.0 |
| SSD form factor | 3.5" |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card | Yes |
| On-board graphics card | No |
| Discrete graphics card model | NVIDIA GeForce RTX 3090 |
| Discrete graphics card memory | 24 GB |
| Discrete graphics memory type | GDDR6X |
| On-board graphics card model | Not available |
Performance
| Specification | Value |
|---|---|
| Product type | PC |
| Motherboard chipset | Intel Z690 |
| Audio output channels | 7.1 channels |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 100,1000 Mbit/s |
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| WLAN controller manufacturer | Intel |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| Bluetooth | Yes |
| Bluetooth version | 5.2 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 0 |
| USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
| Thunderbolt 3 ports quantity | 0 |
| HDMI ports quantity | 1 |
| HDMI version | 2.0 |
| Ethernet LAN (RJ-45) ports | 1 |
| Combo headphone/mic port | Yes |
| Headphone outputs | 1 |
| Microphone in | Yes |
Power
| Specification | Value |
|---|---|
| Power supply | 850 W |
| 80 PLUS certification | 80 PLUS Gold |
Design
| Specification | Value |
|---|---|
| Chassis type | Desktop |
| Product colour | Black |
Software
| Specification | Value |
|---|---|
| Operating system installed | FreeDOS |
Display
| Specification | Value |
|---|---|
| Display included | No |
Processor special features
| Specification | Value |
|---|---|
| CPU configuration (max) | 1 |
| Embedded options available | No |
| Enhanced Intel SpeedStep Technology | Yes |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Intel 64 | Yes |
| Intel Stable Image Platform Program (SIPP) | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Audio
| Specification | Value |
|---|---|
| Audio chip | Realtek ALC897 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 195 mm |
| Depth | 514.8 mm |
| Height | 466 mm |
| Weight | 10 kg |
Packaging data
| Specification | Value |
|---|---|
| Package volume | 40 cm³ |
