CUBI Z AI 8M R7 8845HS FS 16GB 1TB W11P
Model CUBI Z AI 8M R7 8845HS FS 16GB 1TB W11PPart no. CUBI Z AI 8M R7 8845HS FS 16GB 1TB W11
179 specifications
- ProcessorAMD Ryzen™ 7
- Memory16 GB
- Storage1 TB
- SpeedWi-Fi 6E (802.11ax)
- TypeMini PC
- OSWindows 11 Pro
Overview
- Processor
- AMD Ryzen™ 7
- Memory
- 16 GB
- Storage
- 1 TB
- Speed
- Wi-Fi 6E (802.11ax)
- Type
- Mini PC
- OS
- Windows 11 Pro
- Brand
- MSI
- Category
- PCs/Workstations
- Model
- CUBI Z AI 8M R7 8845HS FS 16GB 1TB W11P
- Part number
- CUBI Z AI 8M R7 8845HS FS 16GB 1TB W11
- Also known as
- MSI Cubi Z AI 8M AMD Ryzen 7 8845HS, Desktop PC, SFF, Mini Computer, HTPC, (16GB RAM, 1TB Storage, Windows 11 PRO), AMD Radeon Graphics/DDR5/Dual HDMI/Dual LAN/
Specifications
179 specifications in 22 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | AMD |
| Processor family | AMD Ryzen™ 7 |
| Processor generation | AMD Ryzen 8000 Series |
| Processor model | 8845HS |
| Processor frequency | 3.8 GHz |
| Number of processors installed | 1 |
Neural processor unit (NPU)
| Specification | Value |
|---|---|
| Copilot+ PC | No |
| Neural processor unit (NPU) | AMD Ryzen AI |
| Sparsity support | Yes |
| Windows Studio effects support | Yes |
| AI datatype support on NPU | FP16, Int8 |
| AI software frameworks supported by NPU | Onnx, Windows ML |
Memory
| Specification | Value |
|---|---|
| Internal memory | 16 GB |
| Maximum internal memory | 64 GB |
| Internal memory type | DDR5-SDRAM |
| Memory layout (slots x size) | 2 x 8 GB |
| Memory slots | 2x SO-DIMM |
| Memory clock speed | 5600 MHz |
| Buffered memory type | Unregistered (unbuffered) |
| ECC | No |
| Memory channels | Dual-channel |
| Memory data transfer rate | 5600 MT/s |
| Non-ECC | Yes |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 1 TB |
| Optical drive type | No |
| Storage media | SSD |
| Number of storage drives installed | 1 |
| Number of storage drives supported | 1 |
| Total HDDs capacity | 0 GB |
| Number of HDDs installed | 0 |
| Total SSDs capacity | 1 TB |
| Number of SSDs installed | 1 |
| SSD capacity | 1 TB |
| SSD memory type | TLC |
| NVMe | Yes |
| SSD interface | M.2 |
| SSD form factor | M.2 |
| M.2 SSD size | 2280 (22 x 80 mm) |
| Card reader integrated | Yes |
| Compatible memory cards | Not supported |
| Intel® Optane™ Memory module installed | No |
| Intel® Optane™ Memory module capacity | 0 GB |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card | No |
| On-board graphics card | No |
Performance
| Specification | Value |
|---|---|
| Product type | Mini PC |
| Market positioning | Business |
| Powered by | AMD Ryzen |
| Virtual Reality (VR) ready | No |
| Compatible processor series | AMD Ryzen 8000 Series |
| Password protection | Yes |
| Password protection type | BIOS, Power on, Supervisor |
| Fingerprint reader | No |
| BIOS type | UEFI |
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Audio output channels | 2.0 channels |
| Built-in speaker(s) | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| LAN controller | Realtek RTL8125B |
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| WLAN controller manufacturer | AMD |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| WLAN controller model | AMD RZ616 |
| Antenna type | 2x2 |
| Antenna design | Internal |
| Bluetooth | Yes |
| Bluetooth Low Energy (BLE) | Yes |
| Bluetooth version | 5.3 |
| Wake-on-LAN ready | Yes |
| Miracast | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 5 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 0 |
| USB 3.2 Gen 2x2 Type-C ports quantity | 0 |
| USB4 Gen 2x2 ports quantity | 0 |
| USB4 Gen 3x2 ports quantity | 0 |
| Number of USB ports with PowerShare support | 0 |
| PowerShare | No |
| USB Type-C DisplayPort Alternate Mode | No |
| Thunderbolt 3 ports quantity | 0 |
| Intel® Thunderbolt 4 | No |
| Intel® Thunderbolt 5 | No |
| Thunderbolt 4 ports quantity | 0 |
| Thunderbolt 5 ports quantity | 0 |
| DisplayPorts quantity | 0 |
| HDMI ports quantity | 2 |
| HDMI version | 2.1 |
| Ethernet LAN (RJ-45) ports | 2 |
| Combo headphone/mic port | Yes |
| Headphone outputs | 0 |
| Line-out | No |
| Line-in | No |
| Microphone in | No |
| VGA (D-Sub) ports quantity | 0 |
| DVI port | No |
| Mini DisplayPorts quantity | 0 |
| PS/2 ports quantity | 0 |
| Firewire (IEEE 1394) ports | 0 |
| eSATA ports quantity | 0 |
| S/PDIF out port | No |
| DC-in jack | Yes |
| Serial ports quantity | 0 |
| Parallel ports quantity | 0 |
| Fiber NIC port (Flex I/O) | No |
| Number of front USB ports | 4 |
| Number of front audio ports | 1 |
| Number of rear USB ports | 4 |
| Number of rear audio ports | 0 |
| Number of side USB ports | 0 |
| Total number of SATA connectors | 0 |
| Number of SATA III connectors | 0 |
Expansion slots
| Specification | Value |
|---|---|
| Number of 3.5" bays | 0 |
Power
| Specification | Value |
|---|---|
| Power supply | 120 W |
| Power supply input voltage | 100-240 V |
| Power supply input frequency | 50-60 Hz |
| 80 PLUS certification | No |
Design
| Specification | Value |
|---|---|
| Chassis type | Mini PC |
| Colour name | Black |
| Volume | 0.9 L |
| Placement supported | Horizontal/Vertical |
| VESA mounting | Yes |
| Number of 5.25" bays | 0 |
| Number of 2.5" bays | 0 |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Liquid cooling system | No |
| Copilot key | No |
| Product colour | Black |
| Housing material | Metal, Plastic |
| Introduction month | December |
| Introduction year | 2025 |
| RGB memory lighting | No |
| Viewing window | No |
| Country of origin | China |
| Refurbished | No |
| Certified refurbished | No |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows 11 Pro |
| Operating system architecture | 64-bit |
| Operating system language | English |
| Windows 11 free upgrade | No |
| Apple Intelligence | No |
| Compatible operating systems | Windows 11 Pro |
| Drivers included | Yes |
| Pre-installed software | MSI Center、Nahimic 3 |
Display
| Specification | Value |
|---|---|
| Display included | No |
Processor special features
| Specification | Value |
|---|---|
| Video decode engine | Yes |
| Video encode engine | Yes |
Audio
| Specification | Value |
|---|---|
| Audio chip | Realtek ALC269 |
| Audio system | High Definition Audio |
| Number of speakers | 1 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 35 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 85% |
| Storage relative humidity (H-H) | 0 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 136 mm |
| Depth | 132 mm |
| Height | 50.1 mm |
| Weight | 790 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 469 mm |
| Package depth | 221 mm |
| Package height | 517 mm |
| Package weight | 2 kg |
Packaging content
| Specification | Value |
|---|---|
| Mouse included | No |
| Keyboard included | No |
| Numeric keypad | No |
| Cables included | AC, Power |
| Power cable length | 1.8 m |
| VESA mount included | Yes |
| Manual | Yes |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | CE, Federal Communications Commission (FCC), RoHS, UL |
| Waste Electrical and Electronic Equipment (WEEE) compliance | Yes |
Keyboard
| Specification | Value |
|---|---|
| Keyboard backlit | No |
Other features
| Specification | Value |
|---|---|
| Locale | English |
| Warranty period | 3 year(s) |
