SFP-SX-E network transceiver module Fiber optic 1000 Mbit/s 850 nm
Model SFP-SX-EPart no. SFP-SX-E-ZZBD01FEAN 4718937619214
21 specifications
- Speed1000 Mbit/s
- Weight20 g
- ColourSteel
- SFP transceiver typeFiber optic
- Input voltage3.1-3.5 V
- Width13.4 mm
Overview
- Speed
- 1000 Mbit/s
- Weight
- 20 g
- Colour
- Steel
- SFP transceiver type
- Fiber optic
- Input voltage
- 3.1-3.5 V
- Width
- 13.4 mm
- Brand
- Zyxel
- Category
- Network Transceiver Module
- Model
- SFP-SX-E
- Part number
- SFP-SX-E-ZZBD01F
- EAN / UPC
- 4718937619214
- Also known as
- Zyxel SFP-SX-E network transceiver module Fiber optic 1000 Mbit/s 850 nm
Specifications
21 specifications in 5 groups
Performance
| Specification | Value |
|---|---|
| SFP transceiver type | Fiber optic |
| Maximum data transfer rate | 1000 Mbit/s |
| Interface type | SFP |
| Multi-mode fiber (MMF) supported | Yes |
| Fiber optic connector | LC |
| Maximum transfer distance | 550 m |
| Wavelength | 850 nm |
| Tx power (min) | -3 dBmW |
| Tx power (max) | -9.5 dBmW |
| Rx power (min) | -3 dBmW |
| Rx power (max) | -17 dBmW |
Features
| Specification | Value |
|---|---|
| Product colour | Steel |
| Brand compatibility | Zyxel |
Power
| Specification | Value |
|---|---|
| Input voltage | 3.1-3.5 V |
| Maximum current | 0.3 A |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 13.4 mm |
| Depth | 56 mm |
| Height | 12.4 mm |
| Weight | 20 g |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85369010 |
| Country of origin | China |
