D-Link DEM-211 network transceiver module Fiber optic 100 Mbit/s SFP 1310 nm
D-Link

DEM-211 network transceiver module Fiber optic 100 Mbit/s SFP 1310 nm

Model DEM-211EAN 7900692984240

49 specifications
  • Speed100 Mbit/s
  • TypePlug-in
  • Weight13.6 g
  • ColourMetallic
  • SFP transceiver typeFiber optic
  • Maximum voltage3.3 V
See all specifications

Overview

Speed
100 Mbit/s
Type
Plug-in
Weight
13.6 g
Colour
Metallic
SFP transceiver type
Fiber optic
Maximum voltage
3.3 V
Brand
D-Link
Model
DEM-211
Part number
DEM-211
EAN / UPC
7900692984240, 021200716942, 168141527944, 191120094588 +10 more
Also known as
D-Link DEM-211 network transceiver module Fiber optic 100 Mbit/s SFP 1310 nm

Specifications

49 specifications in 8 groups

Performance

SFP transceiver typeFiber optic
Maximum data transfer rate100 Mbit/s
Interface typeSFP
Multi-mode fiber (MMF) supportedYes
Fiber optic connectorLC
Fiber cable diameters supported (core/cladding)50/125,62.5/125 µm
Maximum transfer distance2000 m
Wavelength1310 nm
Link budget13 dB
Cabling technology100Base-FX
Networking standardsIEEE 802.3u
Fiber ethernet cabling technology100BASE
Duplex systemFull, Half

Features

Product colourMetallic
Form factorPlug-in
Hot-swapYes
Compatible productsDES-1228, DES-1228P, DES-3252P, DES-3228PA, DES-1252, DGS-3612G

Power

Maximum voltage3.3 V

Certificates

SafetyFDA/CDRH, TUV, UL
CertificationRoHS

Operational conditions

Operating temperature (T-T)0 - 70 °C
Storage temperature (T-T)-40 - 85 °C
Operating relative humidity (H-H)10 - 90%
Storage relative humidity (H-H)5 - 90%

Weight & dimensions

Width57.9 mm
Depth12.7 mm
Height7.62 mm
Weight13.6 g

Packaging data

Package width74 mm
Package depth131 mm
Package height49 mm
Package weight64 g

Logistics data

Master (outer) cases per pallet (air)54 pc(s)
Master (outer) cases per pallet (sea)54 pc(s)
Pallet gross length102 cm
Pallet gross weight (air)246.8 kg
Pallet gross weight (sea)246.8 kg
Pallet gross width122 cm
Pallet height (air)199 cm
Pallet height (sea)199 cm
Products per pallet (air)2700 pc(s)
Products per pallet (sea)2700 pc(s)
Products per shipping (inner) case50 pc(s)
Shipping (inner) case gross weight4.2 kg
Shipping (inner) case height31 cm
Shipping (inner) case length36 cm
Shipping (inner) case net weight3.2 kg
Shipping (inner) case width26 cm
Harmonized System (HS) code85369010
