StarTech.com MSA Uncoded SFP Transceiver Module - 100BASE-BX - 100 MbE Ethernet BiDi Fiber (SMF)

StarTech.com MSA Uncoded SFP Transceiver Module - 100BASE-BX - 100 MbE Ethernet BiDi Fiber (SMF)

Model SFP100BBXUSTEAN 065030873512

36 specifications
  • Speed155 Mbit/s
  • Weight18 g
  • ColourSilver
  • SFP transceiver typeFiber optic
  • Power consumption (typical)1 W
  • Operating temperature (T-T)0 - 70 °C
See all specifications

Overview

Speed
155 Mbit/s
Weight
18 g
Colour
Silver
SFP transceiver type
Fiber optic
Power consumption (typical)
1 W
Operating temperature (T-T)
0 - 70 °C
Brand
StarTech.com
Model
SFP100BBXUST
Part number
SFP100BBXUST
EAN / UPC
065030873512
Also known as
StarTech.com MSA Uncoded SFP Transceiver Module - 100BASE-BX - 100 MbE Ethernet BiDi Fiber (SMF)

Specifications

36 specifications in 9 groups

Performance

SFP transceiver typeFiber optic
Maximum data transfer rate155 Mbit/s
Interface typeSFP
Single-mode fiber (SMF) supportedYes
Fiber optic connectorLC
SFP transceiver standardBX
Maximum transfer distance10000 m
Tx wavelength (min)1310 nm
Rx wavelength (min)1550 nm
Networking standardsIEEE 802.3u
Duplex systemFull, Half
Digital Diagnostics Monitoring (DDM)Yes
Wavelength-division multiplexing (WDM)Yes

Features

Product colourSilver
Housing materialAluminium
Hot-Plug supportYes

Power

Power consumption (typical)1 W

Certificates

Compliance certificatesRoHS
CertificationCE, FCC, UR

Operational conditions

Operating temperature (T-T)0 - 70 °C
Storage temperature (T-T)-40 - 85 °C
Operating relative humidity (H-H)5 - 95%

Weight & dimensions

Width16 mm
Depth60 mm
Height11 mm
Weight18 g

Packaging content

Quantity per pack1 pc(s)

Packaging data

Package width94 mm
Package depth114 mm
Package height30 mm
Package weight47 g

Logistics data

Master (outer) case width193 mm
Harmonized System (HS) code85369010
Master (outer) case length307 mm
Master (outer) case height162 mm
Products per master (outer) case20 pc(s)
