SPP13010100BE95 network transceiver module Fiber optic 10000 Mbit/s SFP+ 1310 nm
Model SPP13010100BE95EAN 8716065449808
15 specifications
- Speed10000 Mbit/s
- ColourSteel
- SFP transceiver typeFiber optic
- Minimum operating temperature0 °C
Overview
- Speed
- 10000 Mbit/s
- Colour
- Steel
- SFP transceiver type
- Fiber optic
- Minimum operating temperature
- 0 °C
- Brand
- Skylane Optics
- Category
- Network Transceiver Module
- Model
- SPP13010100BE95
- Part number
- SPP13010100BE95
- EAN / UPC
- 8716065449808
- Also known as
- Skylane Optics SPP13010100BE95 network transceiver module Fiber optic 10000 Mbit/s SFP+ 1310 nm
Specifications
15 specifications in 5 groups
Performance
| Specification | Value |
|---|---|
| SFP transceiver type | Fiber optic |
| Maximum data transfer rate | 10000 Mbit/s |
| Interface type | SFP+ |
| Single-mode fiber (SMF) supported | Yes |
| Fiber optic connector | LC |
| Maximum transfer distance | 10000 m |
| Wavelength | 1310 nm |
| Tx wavelength (max) | 1310 nm |
| Rx wavelength (max) | 1310 nm |
| Ethernet interface type | 10 Gigabit Ethernet |
Features
| Specification | Value |
|---|---|
| Product colour | Steel |
Operational conditions
| Specification | Value |
|---|---|
| Minimum operating temperature | 0 °C |
| Maximum operating temperature | 70 °C |
Packaging content
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85369010 |
