P7D7R Dell Compatible Transceiver SFP28 25GBase-SR (850nm MMF 100m LC DOM)
Model P7D7R-OSEAN 5059902184412
24 specifications
- Speed25000 Mbit/s
- ColourSilver
- SFP transceiver typeFiber optic
- Minimum operating temperature0 °C
Overview
- Speed
- 25000 Mbit/s
- Colour
- Silver
- SFP transceiver type
- Fiber optic
- Minimum operating temperature
- 0 °C
- Brand
- Origin Storage
- Category
- Network Transceiver Module
- Model
- P7D7R-OS
- Part number
- P7D7R-OS
- EAN / UPC
- 5059902184412
- Also known as
- Origin Storage P7D7R Dell Compatible Transceiver SFP28 25GBase-SR (850nm MMF 100m LC DOM)
Specifications
24 specifications in 7 groups
Performance
| Specification | Value |
|---|---|
| SFP transceiver type | Fiber optic |
| Maximum data transfer rate | 25000 Mbit/s |
| Interface type | SFP28 |
| Single-mode fiber (SMF) supported | No |
| Multi-mode fiber (MMF) supported | Yes |
| Fiber optic connector | LC |
| Maximum transfer distance | 100 m |
| Wavelength | 850 nm |
| Ethernet interface type | 25 Gigabit Ethernet |
Features
| Specification | Value |
|---|---|
| Product colour | Silver |
| Housing material | Metal |
| Plug and Play | Yes |
| Hot-Plug support | Yes |
| Hot-swap | Yes |
| Easy to install | Yes |
| Brand compatibility | Dell |
Certificates
| Specification | Value |
|---|---|
| Certification | CE, FCC, RoHS, REACH |
Sustainability
| Specification | Value |
|---|---|
| Doesn't contain | Lead |
Operational conditions
| Specification | Value |
|---|---|
| Minimum operating temperature | 0 °C |
| Maximum operating temperature | 70 °C |
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
Packaging data
| Specification | Value |
|---|---|
| Package type | Blister |
Logistics data
| Specification | Value |
|---|---|
| Warranty period | 20 year(s) |
