1.25Gbps Single-mode BIDI SFP Transceiver, 10km, TX 1310nm / RX 1550nm
Model SFP-9221EAN 4015867154779
31 specifications
- Speed1250 Mbit/s
- Weight20 g
- SFP transceiver typeFiber optic
- Hot-swapYes
- Input voltage3.3 V
- Operating temperature (T-T)0 - 70 °C
Overview
- Speed
- 1250 Mbit/s
- Weight
- 20 g
- SFP transceiver type
- Fiber optic
- Hot-swap
- Yes
- Input voltage
- 3.3 V
- Operating temperature (T-T)
- 0 - 70 °C
- Brand
- LevelOne
- Category
- Network Transceiver Module
- Model
- SFP-9221
- Part number
- SFP-9221
- EAN / UPC
- 4015867154779, 4015867240625, 5050914832476
- Also known as
- LevelOne 1.25Gbps Single-mode BIDI SFP Transceiver, 10km, TX 1310nm / RX 1550nm
Specifications
31 specifications in 9 groups
Performance
| Specification | Value |
|---|---|
| SFP transceiver type | Fiber optic |
| Maximum data transfer rate | 1250 Mbit/s |
| Interface type | SFP |
| Single-mode fiber (SMF) supported | Yes |
| Fiber optic connector | LC |
| Fiber cable diameters supported (core/cladding) | 9/125 µm |
| Maximum transfer distance | 10000 m |
| Tx power (min) | -9 dBmW |
| Tx power (max) | -3 dBmW |
| Networking standards | IEEE 802.3z |
| Fiber ports quantity | 1 |
Features
| Specification | Value |
|---|---|
| Hot-swap | Yes |
Power
| Specification | Value |
|---|---|
| Input voltage | 3.3 V |
| Maximum voltage | 6 V |
| Maximum current | 0.3 A |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
| Safety | EN 60825-1 |
| Certification | CE, FCC |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 5 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 13.7 mm |
| Depth | 56.6 mm |
| Height | 8.95 mm |
| Weight | 20 g |
Packaging content
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
Packaging data
| Specification | Value |
|---|---|
| Package width | 76 mm |
| Package depth | 50 mm |
| Package height | 130 mm |
| Package weight | 60 g |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85369010 |
