SFP-BX43-40-I network transceiver module Fiber optic 1000 Mbit/s
Model SFP-BX43-40-IPart no. PAN-SFP-BX-D-40-A
30 specifications
- Speed1000 Mbit/s
- TypeSFP
- ColourMetallic
- SFP transceiver typeFiber optic
- Input voltage3.3 V
- Minimum operating temperature-40 °C
Overview
- Speed
- 1000 Mbit/s
- Type
- SFP
- Colour
- Metallic
- SFP transceiver type
- Fiber optic
- Input voltage
- 3.3 V
- Minimum operating temperature
- -40 °C
- Brand
- Legrand
- Category
- Network Transceiver Module
- Model
- SFP-BX43-40-I
- Part numbers
- PAN-SFP-BX-D-40-A, 3FE65571AB-A, E1MG-BXD-40-A, GLC-BX40-DA-I-A, GLC-BX40-D-I-A, XCVR-040U55-43-A +4 more
- Also known as
- Legrand SFP-BX43-40-I network transceiver module Fiber optic 1000 Mbit/s
Specifications
30 specifications in 7 groups
Performance
| Specification | Value |
|---|---|
| SFP transceiver type | Fiber optic |
| Maximum data transfer rate | 1000 Mbit/s |
| Interface type | SFP |
| Single-mode fiber (SMF) supported | Yes |
| SFP transceiver standard | BX-D |
| Maximum transfer distance | 40000 m |
| Tx wavelength (min) | 1490 nm |
| Tx wavelength (max) | 1490 nm |
| Rx wavelength (min) | 1310 nm |
| Rx wavelength (max) | 1310 nm |
| Ethernet interface type | Gigabit Ethernet |
| Fiber ethernet cabling technology | 1000BASE |
| Digital Diagnostics Monitoring (DDM) | Yes |
Features
| Specification | Value |
|---|---|
| Product colour | Metallic |
| Form factor | SFP |
| Plug and Play | Yes |
| Hot-Plug support | Yes |
| Easy to install | Yes |
| Brand compatibility | Alcatel |
Power
| Specification | Value |
|---|---|
| Input voltage | 3.3 V |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Operational conditions
| Specification | Value |
|---|---|
| Minimum operating temperature | -40 °C |
| Maximum operating temperature | 85 °C |
| Operating temperature (T-T) | -40 - 85 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 0 - 85% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 13.7 mm |
| Depth | 56.6 mm |
| Height | 12.8 mm |
Packaging content
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
