QSFP-PLR4 network transceiver module Fiber optic 41200 Mbit/s QSFP+ 1310 nm
Model QSFP-PLR4Part no. QSF-506-AEAN 840445701526
28 specifications
- Speed41200 Mbit/s
- TypeQSFP+
- ColourMetallic
- SFP transceiver typeFiber optic
- Input voltage3.3 V
- Minimum operating temperature0 °C
Overview
- Speed
- 41200 Mbit/s
- Type
- QSFP+
- Colour
- Metallic
- SFP transceiver type
- Fiber optic
- Input voltage
- 3.3 V
- Minimum operating temperature
- 0 °C
- Brand
- Legrand
- Category
- Network Transceiver Module
- Model
- QSFP-PLR4
- Part numbers
- QSF-506-A, QSFP-40G-LRM4-A, QSFP-40G-PLRL4-A, QSFP-4X10G-LR-S-A, QSFP-IR4-MPO-GDY-A, QSFP-PLR4-A +5 more
- EAN / UPC
- 840445701526
- Also known as
- Legrand QSFP-PLR4 network transceiver module Fiber optic 41200 Mbit/s QSFP+ 1310 nm
Specifications
28 specifications in 7 groups
Performance
| Specification | Value |
|---|---|
| SFP transceiver type | Fiber optic |
| Maximum data transfer rate | 41200 Mbit/s |
| Interface type | QSFP+ |
| Single-mode fiber (SMF) supported | Yes |
| Fiber optic connector | MTP/MPO |
| SFP transceiver standard | PSM4 |
| Maximum transfer distance | 10000 m |
| Wavelength | 1310 nm |
| Ethernet interface type | 40 Gigabit Ethernet |
| Fiber ethernet cabling technology | 40GBASE |
| Digital Diagnostics Monitoring (DDM) | Yes |
Features
| Specification | Value |
|---|---|
| Product colour | Metallic |
| Form factor | QSFP+ |
| Plug and Play | Yes |
| Hot-Plug support | Yes |
| Easy to install | Yes |
| Brand compatibility | Alcatel |
Power
| Specification | Value |
|---|---|
| Input voltage | 3.3 V |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Operational conditions
| Specification | Value |
|---|---|
| Minimum operating temperature | 0 °C |
| Maximum operating temperature | 70 °C |
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 5 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 18.4 mm |
| Depth | 126 mm |
| Height | 8.5 mm |
Packaging content
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
