BTI-MGBIC-GTX-L network transceiver module Copper 1000 Mbit/s SFP
Model BTI-MGBIC-GTX-L
20 specifications
- Speed1000 Mbit/s
- TypeSFP
- ColourSilver
- SFP transceiver typeCopper
- Operating temperature (T-T)0 - 70 °C
- Width13.4 mm
Overview
- Speed
- 1000 Mbit/s
- Type
- SFP
- Colour
- Silver
- SFP transceiver type
- Copper
- Operating temperature (T-T)
- 0 - 70 °C
- Width
- 13.4 mm
- Brand
- Legrand
- Category
- Network Transceiver Module
- Model
- BTI-MGBIC-GTX-L
- Part number
- BTI-MGBIC-GTX-L
- Also known as
- Legrand BTI-MGBIC-GTX-L network transceiver module Copper 1000 Mbit/s SFP
Specifications
20 specifications in 5 groups
Performance
| Specification | Value |
|---|---|
| SFP transceiver type | Copper |
| Maximum data transfer rate | 1000 Mbit/s |
| Interface type | SFP |
| SFP transceiver standard | TX |
| Maximum transfer distance | 100 m |
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Copper ethernet cabling technology | 1000BASE |
| Ethernet LAN (RJ-45) ports | 1 |
Features
| Specification | Value |
|---|---|
| Product colour | Silver |
| Form factor | SFP |
| Hot-Plug support | Yes |
| Hot-swap | Yes |
| Easy to install | Yes |
| Brand compatibility | Telco Systems |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 70 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 13.4 mm |
| Depth | 56.6 mm |
| Height | 8.5 mm |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | China |
