Lanview MO-UF-SM-1G-S-2 network transceiver module Fiber optic 1000 Mbit/s SFP

Lanview MO-UF-SM-1G-S-2 network transceiver module Fiber optic 1000 Mbit/s SFP

Model MO-UF-SM-1G-S-2EAN 5711783997351

28 specifications

Speed1000 Mbit/s
Weight30 g
SFP transceiver typeFiber optic
Plug and PlayYes
Operating temperature (T-T)-45 - 75 °C
Width80 mm

See all specifications

Overview

Speed: 1000 Mbit/s
Weight: 30 g
SFP transceiver type: Fiber optic
Plug and Play: Yes
Operating temperature (T-T): -45 - 75 °C
Width: 80 mm

Brand: Lanview
Category: Network Transceiver Module
Model: MO-UF-SM-1G-S-2
Part number: MO-UF-SM-1G-S-2
EAN / UPC: 5711783997351
Also known as: Lanview MO-UF-SM-1G-S-2 network transceiver module Fiber optic 1000 Mbit/s SFP

Specifications

28 specifications in 7 groups

Performance

Specification	Value
SFP transceiver type	Fiber optic
Maximum data transfer rate	1000 Mbit/s
Interface type	SFP
Single-mode fiber (SMF) supported	Yes
Multi-mode fiber (MMF) supported	No
Maximum transfer distance	3000 m
Tx wavelength (min)	1310 nm
Rx wavelength (min)	1550 nm
Duplex system	Full
Digital Diagnostics Monitoring (DDM)	Yes
Fiber ports quantity	1

Features

Specification	Value
Plug and Play	Yes
Easy to install	Yes
Compatible products	Ubiquiti UF-SM-1G-S

Certificates

Specification	Value
Certification	MSA

Operational conditions

Specification	Value
Operating temperature (T-T)	-45 - 75 °C
Storage temperature (T-T)	-40 - 85 °C
Storage relative humidity (H-H)	10 - 85%

Weight & dimensions

Specification	Value
Width	80 mm
Depth	80 mm
Height	30 mm
Weight	30 g

Packaging content

Specification	Value
Quantity per pack	1 pc(s)

Packaging data

Specification	Value
Package width	80 mm
Package depth	80 mm
Package height	30 mm
Package weight	40 g
Package type	Window box
