CE0128TB SWITCH-LLW
Model CE0128TB SWITCH-LLWPart no. 7Z360011WWEAN 889488479627
68 specifications
- Type1U
- Weight3.7 kg
- ColourBlack
- Switch typeManaged
- Basic switching RJ-45 Ethernet ports quantity24
- 10G supportYes
Overview
- Type
- 1U
- Weight
- 3.7 kg
- Colour
- Black
- Switch type
- Managed
- Basic switching RJ-45 Ethernet ports quantity
- 24
- 10G support
- Yes
- Brand
- Lenovo
- Category
- Network Switch
- Model
- CE0128TB SWITCH-LLW
- Part number
- 7Z360011WW
- EAN / UPC
- 889488479627, 8894884796270
- Also known as
- Lenovo CE0128TB SWITCH-LLW Managed L2+/L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Black
Specifications
68 specifications in 16 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Managed |
| Switch layer | L2+/L3 |
| Quality of Service (QoS) support | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| SFP+ module slots quantity | 4 |
| Console port | RJ-45 |
| Power connector | AC-in jack |
Network
| Specification | Value |
|---|---|
| 10G support | Yes |
| Copper ethernet cabling technology | 100BASE-T |
| Cable types supported | Cat5, Cat5e |
| Port mirroring | Yes |
| Full duplex | Yes |
| IP routing | Yes |
| Policy-based routing | Yes |
| Routing entries | 512 |
| Flow control support | Yes |
| Link aggregation | Yes |
| Spanning tree protocol | Yes |
| VLAN support | Yes |
| Virtual LAN features | Tagged VLAN |
| Number of VLANs | 4093 |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 16384 entries |
| Throughput | 95000000 Mpps |
| Latency (1 Gbps) | 4 µs |
| Latency (10 Gbps) | 2 µs |
| Number of IP interfaces | 192 |
| Jumbo frames support | Yes |
| Jumbo frames | 9216 |
| Packet buffer memory | 1.5 MB |
Security
| Specification | Value |
|---|---|
| DHCP features | DHCP client, DHCP relay, DHCP server |
| Access Control List (ACL) | Yes |
| Access Control List (ACL) IPv4 entries | 256 |
| Access Control List (ACL) IPv6 entries | 256 |
| Authentication type | RADIUS |
| SSH/SSL support | Yes |
| Security algorithms | SNMP, SNMPv3, SSH |
Multicast features
| Specification | Value |
|---|---|
| Multicast support | Yes |
Protocols
| Specification | Value |
|---|---|
| Management protocols | IPv4/IPv6 |
| GARP VLAN Registration Protocol (GVRP) | Yes |
| Routing protocols | VRRP |
Design
| Specification | Value |
|---|---|
| Rack mounting | Yes |
| Stackable | Yes |
| Form factor | 1U |
| Product colour | Black |
| LED indicators | Yes |
| Airflow direction | Side-to-side airflow |
| Number of fans | 3 fan(s) |
Performance
| Specification | Value |
|---|---|
| Physical stacking (units) | 8 |
| Mean time between failures (MTBF) | 600000 h |
Power
| Specification | Value |
|---|---|
| Power supply included | Yes |
| Number of power supply units | 1 |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (typical) | 260 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) ports quantity | 24 |
| Power over Ethernet (PoE) power per port | 30 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating altitude | 0 - 3000 m |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 441 mm |
| Depth | 254 mm |
| Height | 44 mm |
| Weight | 3.7 kg |
Packaging content
| Specification | Value |
|---|---|
| Manual | Yes |
Certificates
| Specification | Value |
|---|---|
| Certification | FCC Part 15, Class A; UL 60950-1 / UL 62368-1, ICES-003, Issue 6, Class A; CSA C22.2 60950-1 / CSA C22.2 62368-1, NOM-19, IEC 60950-1, RoHS, CE Mark, TUV-GS, EAC, CCC GB4943.1, GB/T9254, YD/T993, CECP CQC3140, VCCI-CISPR32:2016, Class A, BSMI CNS13438, Class A; CNS14336-1, KN32, Class A; KN35, AS/NZ |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
