MC1000-SFP-FP network media converter
Model MC1000-SFP-FPPart no. 91-010-157001B
12 specifications
- ConnectivityWired
- Weight292 g
- Operating temperature (T-T)0 - 45 °C
Overview
- Connectivity
- Wired
- Weight
- 292 g
- Operating temperature (T-T)
- 0 - 45 °C
- Brand
- Zyxel
- Category
- Network Media Converter
- Model
- MC1000-SFP-FP
- Part numbers
- 91-010-157001B, 3100, ZYX-MC1000-SFP-FP
- Also known as
- Zyxel MC1000-SFP-FP network media converter
Specifications
12 specifications in 6 groups
Features
| Specification | Value |
|---|---|
| Compliance industry standards | IEEE802.3 10BASE-T, IEEE802.3u 100BASE-TX/FX, IEEE802.3ab 1000BASE-T, IEEE802.3z 1000BASE-X |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 292 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
Certificates
| Specification | Value |
|---|---|
| Safety | CE LVD |
| Certification | FCC Part15 (Class B), CE EMC |
Other features
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 194 x 129 x 25 mm |
| Interface | 1x 1000BASE-T, 1x 1000BASE-X SFP |
| Power requirements | 12V DC/ 0.8A |
