RJ45 to SFP Gigabit Media Converter, 802.3bt
60W PoE PSE
Model GVT-2015EAN 846359060681
56 specifications
- Speed1000 Mbit/s
- ConnectivityWired
- Weight320 g
- ColourBlack
- Fiber mode structureMulti-mode, Single-mode
- InternalNo
Overview
- Speed
- 1000 Mbit/s
- Connectivity
- Wired
- Weight
- 320 g
- Colour
- Black
- Fiber mode structure
- Multi-mode, Single-mode
- Internal
- No
- Brand
- LevelOne
- Category
- Network Media Converter
- Model
- GVT-2015
- Part number
- GVT-2015
- EAN / UPC
- 846359060681, 4015867238004
- Also known as
- LevelOne RJ45 to SFP Gigabit Media Converter, 802.3bt 60W PoE PSE
Specifications
56 specifications in 11 groups
Network
| Specification | Value |
|---|---|
| Maximum data transfer rate | 1000 Mbit/s |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Ethernet interface type | Fast Ethernet, Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Copper ethernet cabling technology | 100BASE-TX, 1000BASE-T, 1000BASE-X |
| Jumbo frames support | Yes |
| Jumbo frames | 9000 |
| Flow control support | Yes |
| Auto MDI/MDI-X | Yes |
| Auto-negotiation | Yes |
Performance
| Specification | Value |
|---|---|
| Fiber mode structure | Multi-mode, Single-mode |
Features
| Specification | Value |
|---|---|
| Internal | No |
| Web-based management | No |
| LED indicators | LAN, PoE, Power |
| Product colour | Black |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Ethernet LAN (RJ-45) ports | 1 |
| Fiber ports quantity | 1 |
| Fiber optic connector | SFP |
| Power over Ethernet plus (PoE+) ports quantity | 1 |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| Input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 1.8 A |
| Output voltage | 54.5 V |
| Output current | 1.32 A |
| Power consumption (typical) | 0.97 W |
| Power consumption (max) | 72.4 W |
| Power over Ethernet (PoE) | Yes |
| Total Power over Ethernet (PoE) budget | 60 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 93.5 mm |
| Depth | 70 mm |
| Height | 26 mm |
| Weight | 320 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -40 - 80 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Quick installation guide | Yes |
Packaging data
| Specification | Value |
|---|---|
| Package width | 240 mm |
| Package depth | 186 mm |
| Package height | 84 mm |
| Package weight | 715 g |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | CE, Federal Communications Commission (FCC), Low Voltage Directive (LVD), RCM, RoHS, UKCA |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | China |
| Harmonized System (HS) code | 851762 |
| Master (outer) cases per pallet (air) | 32 pc(s) |
| Pallet gross length | 100 cm |
| Pallet gross width | 120 cm |
| Pallet height (air) | 171 cm |
| Master (outer) case width | 450 mm |
| Master (outer) case length | 264 mm |
| Master (outer) case height | 390 mm |
| Master (outer) case gross weight | 8.24 kg |
| Products per master (outer) case | 10 pc(s) |
