VDS-1202 network media converter 100 Mbit/s Grey
Model VDS-1202EAN 4015867209073
35 specifications
- Speed100 Mbit/s
- ConnectivityWired
- Weight330 g
- ColourGrey
- Maximum transfer distance1500 m
- InternalNo
Overview
- Speed
- 100 Mbit/s
- Connectivity
- Wired
- Weight
- 330 g
- Colour
- Grey
- Maximum transfer distance
- 1500 m
- Internal
- No
- Brand
- LevelOne
- Category
- Network Media Converter
- Model
- VDS-1202
- Part number
- VDS-1202
- EAN / UPC
- 4015867209073
- Also known as
- LevelOne VDS-1202 network media converter 100 Mbit/s Grey
Specifications
35 specifications in 11 groups
Network
| Specification | Value |
|---|---|
| Maximum data transfer rate | 100 Mbit/s |
| Networking standards | IEEE 802.3, IEEE 802.3u |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-T |
| Data transfer rate | 100 Mbit/s |
| Auto MDI/MDI-X | Yes |
| Duplex system | Full, Half |
| Modulation | DMT |
Performance
| Specification | Value |
|---|---|
| Maximum transfer distance | 1500 m |
Features
| Specification | Value |
|---|---|
| Internal | No |
| Housing material | Metal |
| LED indicators | DSL, LAN, Power |
| Product colour | Grey |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Ethernet LAN (RJ-45) ports | 2 |
| RJ-11 ports quantity | 2 |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| Input voltage | 12 V |
| Input current | 1 A |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 90 mm |
| Depth | 120 mm |
| Height | 28 mm |
| Weight | 330 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | 5 - 95 °C |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Quick installation guide | Yes |
Packaging data
| Specification | Value |
|---|---|
| Package width | 150 mm |
| Package depth | 235 mm |
| Package height | 80 mm |
| Package weight | 600 g |
| Package type | Box |
Certificates
| Specification | Value |
|---|---|
| Certification | CE, FCC, LVD, JATE |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | China |
| Harmonized System (HS) code | 85176990 |
