LevelOne RJ45 to ST Fast Ethernet Industrial Media Converter, Multi-Mode Fiber, 2km, -40°C to 75°C
Model IEC-4002EAN 4015867188156
37 specifications
- Speed100 Mbit/s
- ConnectivityWired
- Weight90 g
- ColourBlack
- Maximum transfer distance2000 m
- InternalNo
Overview
- Speed
- 100 Mbit/s
- Connectivity
- Wired
- Weight
- 90 g
- Colour
- Black
- Maximum transfer distance
- 2000 m
- Internal
- No
- Brand
- LevelOne
- Category
- Network Media Converter
- Model
- IEC-4002
- Part number
- IEC-4002
- EAN / UPC
- 4015867188156
- Also known as
- LevelOne RJ45 to ST Fast Ethernet Industrial Media Converter, Multi-Mode Fiber, 2km, -40°C to 75°C
Specifications
37 specifications in 11 groups
Network
| Specification | Value |
|---|---|
| Maximum data transfer rate | 100 Mbit/s |
| Converter input interface | 10Base-T, 100Base-TX |
| Converter output interface | 100Base-FX |
| Networking standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
| Flow control support | Yes |
| Auto MDI/MDI-X | Yes |
| Auto-negotiation | Yes |
| Duplex system | Full, Half |
Performance
| Specification | Value |
|---|---|
| Maximum transfer distance | 2000 m |
| Fiber mode structure | Multi-mode |
Features
| Specification | Value |
|---|---|
| Internal | No |
| Housing material | Aluminium |
| LED indicators | Activity, Link, Power |
| Product colour | Black |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Ethernet LAN (RJ-45) ports | 1 |
| Fiber ports quantity | 1 |
| Fiber optic connector | ST |
Power
| Specification | Value |
|---|---|
| Input voltage | 12 - 60 V |
| Power consumption (typical) | 1.44 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 59 mm |
| Depth | 49 mm |
| Height | 36 mm |
| Weight | 90 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -40 - 75 °C |
| Storage temperature (T-T) | -40 - 75 °C |
| Operating relative humidity (H-H) | 5 - 95% |
Packaging content
| Specification | Value |
|---|---|
| Quick installation guide | Yes |
Packaging data
| Specification | Value |
|---|---|
| Package width | 160 mm |
| Package depth | 105 mm |
| Package height | 65 mm |
| Package weight | 260 g |
| Package type | Box |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
| Certification | FCC Part 15 Subpart B Class A CE EN 55022 Class A FCC Part 15 Subpart B Class A, CE EN 55022 Class A EN61000-4-2 (ESD) Level 3 EN61000-4-3 (RS) Level 2 EN61000-4-4 (EFT) Level 2 EN61000-4-5 (Surge) Level 2 EN61000-4-6 (CS) Level 2 EN 61000-4-8 (PFMF) Level 1 UL508 (Pending) EN 50121-4 (Pending) IEC |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | Taiwan |
| Harmonized System (HS) code | 85176990 |
