LevelOne RJ45 to SFP Gigabit Industrial Media Converter, -40°C to 75°C
Model IEC-2000EAN 4015867184103
41 specifications
- Speed1000 Mbit/s
- ConnectivityWired
- Weight800 g
- ColourBlack
- Mean time between failures (MTBF)665760 h
- InternalNo
Overview
- Speed
- 1000 Mbit/s
- Connectivity
- Wired
- Weight
- 800 g
- Colour
- Black
- Mean time between failures (MTBF)
- 665760 h
- Internal
- No
- Brand
- LevelOne
- Category
- Network Media Converter
- Model
- IEC-2000
- Part number
- IEC-2000
- EAN / UPC
- 4015867184103, 5050914832865
- Also known as
- LevelOne RJ45 to SFP Gigabit Industrial Media Converter, -40°C to 75°C
Specifications
41 specifications in 11 groups
Network
| Specification | Value |
|---|---|
| Maximum data transfer rate | 1000 Mbit/s |
| Converter input interface | 10Base-T, 100Base-TX, 1000Base-TX |
| Converter output interface | 1000Base-LX, 1000Base-SX |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Packet forwarding rate (1 Gbps) | 1488100 pps |
| Auto MDI/MDI-X | Yes |
| Auto-negotiation | Yes |
| Duplex system | Full, Half |
Performance
| Specification | Value |
|---|---|
| Mean time between failures (MTBF) | 665760 h |
Features
| Specification | Value |
|---|---|
| Internal | No |
| DIN rail mounting | Yes |
| Housing material | Aluminium |
| International Protection (IP) code | IP30 |
| LED indicators | Activity, Link, Power, Status |
| Product colour | Black |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Ethernet LAN (RJ-45) ports | 1 |
| Fiber ports quantity | 1 |
| Fiber optic connector | SFP |
Power
| Specification | Value |
|---|---|
| Input voltage | 12 - 48 V |
| Output current (48V) | 0.16 A |
| Power consumption (max) | 7.68 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 50 mm |
| Depth | 110 mm |
| Height | 135 mm |
| Weight | 800 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -40 - 75 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 5 - 95% |
Packaging content
| Specification | Value |
|---|---|
| Quick installation guide | Yes |
Packaging data
| Specification | Value |
|---|---|
| Package width | 198 mm |
| Package depth | 92 mm |
| Package height | 236 mm |
| Package weight | 1 kg |
| Package type | Box |
Certificates
| Specification | Value |
|---|---|
| Safety | UL508 |
| Certification | - ISO9001 - FCC Part 15, Class A - EN61000-6-3 - EN55022 - EN61000-3-2 - EN61000-3-3 - EN61000-6-2 - EN61000-4-2 - EN61000-4-3 - EN61000-4-4 - EN61000-4-5 - EN61000-4-6 - EN61000-4-8 - IEC60068-2-6 Fc - IEC60068-2-27 Ea - FED STD 101C Method 5007.1 |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | Taiwan |
| Harmonized System (HS) code | 85176990 |
