RJ45 to SFP+ 10-Gigabit Media Converter
Model GVT-2051EAN 846359060636
46 specifications
- Speed10000 Mbit/s
- ConnectivityWired
- Weight300 g
- ColourBlack
- InternalNo
- Output voltage5 V
Overview
- Speed
- 10000 Mbit/s
- Connectivity
- Wired
- Weight
- 300 g
- Colour
- Black
- Internal
- No
- Output voltage
- 5 V
- Brand
- LevelOne
- Category
- Network Media Converter
- Model
- GVT-2051
- Part number
- GVT-2051
- EAN / UPC
- 846359060636, 4015867236758
- Also known as
- LevelOne RJ45 to SFP+ 10-Gigabit Media Converter
Specifications
46 specifications in 11 groups
Network
| Specification | Value |
|---|---|
| Maximum data transfer rate | 10000 Mbit/s |
| Converter input interface | 10GBase-T |
| Networking standards | IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3z |
| Ethernet interface type | 2.5 Gigabit Ethernet, 5 Gigabit Ethernet, 10 Gigabit Ethernet, Gigabit Ethernet |
| Ethernet LAN data rates | 1000,2500,5000,10000 Mbit/s |
Features
| Specification | Value |
|---|---|
| Internal | No |
| Plug and Play | Yes |
| LED indicators | Yes |
| Product colour | Black |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Ethernet LAN (RJ-45) ports | 1 |
| Fiber ports quantity | 1 |
| Fiber optic connector | SFP+ |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| Output voltage | 5 V |
| Output current | 2 A |
| Power consumption (typical) | 6.7 W |
| External power adapter | Yes |
Sustainability
| Specification | Value |
|---|---|
| Sustainability compliance | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 71 mm |
| Depth | 94 mm |
| Height | 26 mm |
| Weight | 300 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 0 - 95% |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Quick installation guide | Yes |
| User guide | Yes |
Packaging data
| Specification | Value |
|---|---|
| Package width | 118 mm |
| Package depth | 78 mm |
| Package height | 86 mm |
| Package weight | 350 g |
| Package type | Box |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | CE, RoHS, UKCA |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | China |
| Harmonized System (HS) code | 8517620090 |
| Master (outer) cases per pallet (air) | 27 pc(s) |
| Pallet gross length | 80 cm |
| Pallet gross width | 120 cm |
| Pallet height (air) | 165 cm |
| Master (outer) case width | 250 mm |
| Master (outer) case length | 280 mm |
| Master (outer) case height | 500 mm |
| Master (outer) case gross weight | 13.2 kg |
| Products per master (outer) case | 36 pc(s) |
