RJ45 to SC Gigabit Media Converter, PoE PSE, Single-Mode Fiber, 20km
Model GVT-2014EAN 846359059272
52 specifications
- Speed1000 Mbit/s
- ConnectivityWired
- Weight200 g
- ColourGrey
- Maximum transfer distance20000 m
- InternalNo
Overview
- Speed
- 1000 Mbit/s
- Connectivity
- Wired
- Weight
- 200 g
- Colour
- Grey
- Maximum transfer distance
- 20000 m
- Internal
- No
- Brand
- LevelOne
- Category
- Network Media Converter
- Model
- GVT-2014
- Part number
- GVT-2014
- EAN / UPC
- 846359059272, 4015867231227, 4015867239544
- Also known as
- LevelOne RJ45 to SC Gigabit Media Converter, PoE PSE, Single-Mode Fiber, 20km
Specifications
52 specifications in 10 groups
Network
| Specification | Value |
|---|---|
| Maximum data transfer rate | 1000 Mbit/s |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-T, 1000BASE-T |
| Jumbo frames support | Yes |
| Jumbo frames | 9000 |
| Flow control support | Yes |
| Auto MDI/MDI-X | Yes |
| Auto-negotiation | Yes |
| Store-and-forward | Yes |
| Duplex system | Full, Half |
Performance
| Specification | Value |
|---|---|
| Maximum transfer distance | 20000 m |
| Wavelength | 1310 nm |
| Fiber mode structure | Single-mode |
Features
| Specification | Value |
|---|---|
| Internal | No |
| LED indicators | Activity, Link, Power |
| Product colour | Grey |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Ethernet LAN (RJ-45) ports | 1 |
| Fiber ports quantity | 1 |
| Fiber optic connector | SC |
Power
| Specification | Value |
|---|---|
| Input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 1.6 A |
| Output voltage | 48 V |
| Output current | 2 A |
| Power consumption (max) | 40 W |
| Power over Ethernet (PoE) | Yes |
| Total Power over Ethernet (PoE) budget | 30 W |
| External power adapter | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 70 mm |
| Depth | 94 mm |
| Height | 26 mm |
| Weight | 200 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 60 °C |
| Operating relative humidity (H-H) | 5 - 90% |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| User guide | Yes |
Packaging data
| Specification | Value |
|---|---|
| Package width | 230 mm |
| Package depth | 150 mm |
| Package height | 60 mm |
| Package weight | 650 g |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | China |
| Master (outer) cases per pallet (air) | 23 pc(s) |
| Pallet gross length | 80 cm |
| Pallet gross width | 120 cm |
| Pallet height (air) | 176.9 cm |
| Master (outer) case width | 480 mm |
| Master (outer) case length | 305 mm |
| Master (outer) case height | 325 mm |
| Master (outer) case gross weight | 13.8 kg |
| Products per master (outer) case | 20 pc(s) |
