RJ45 to SC Fast Ethernet Media Converter, 1 PoE Output, 802.3af PoE, Single-Mode Fiber, 20km
Model FVT-0204TXFCEAN 4014619102099
35 specifications
- Speed100 Mbit/s
- ConnectivityWired
- Maximum transfer distance20000 m
- InternalNo
- Input voltage100 - 240 V
- Width158 mm
Overview
- Speed
- 100 Mbit/s
- Connectivity
- Wired
- Maximum transfer distance
- 20000 m
- Internal
- No
- Input voltage
- 100 - 240 V
- Width
- 158 mm
- Brand
- LevelOne
- Category
- Network Media Converter
- Model
- FVT-0204TXFC
- Part number
- FVT-0204TXFC
- EAN / UPC
- 4014619102099, 4015867125687, 5050914833039
- Also known as
- LevelOne RJ45 to SC Fast Ethernet Media Converter, 1 PoE Output, 802.3af PoE, Single-Mode Fiber, 20km
Specifications
35 specifications in 10 groups
Network
| Specification | Value |
|---|---|
| Maximum data transfer rate | 100 Mbit/s |
| Converter input interface | 10Base-T, 100Base-TX |
| Converter output interface | 100Base-FX |
| Networking standards | IEEE 802.3, IEEE 802.3af, IEEE 802.3u, IEEE 802.3x |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Packet forwarding rate (10 Mbps) | 14880 pps |
| Packet forwarding rate (100 Mbps) | 148800 pps |
| Duplex system | Full, Half |
| Cable types supported | Fiber |
Performance
| Specification | Value |
|---|---|
| Maximum transfer distance | 20000 m |
| Fiber mode structure | Single-mode |
| Fiber cable diameters supported (core/cladding) | 8.3/125,8.7/125,9/125,10/125 µm |
Features
| Specification | Value |
|---|---|
| Internal | No |
| LED indicators | FDX, Activity, Link, PoE, Power |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Ethernet LAN (RJ-45) ports | 1 |
| Fiber ports quantity | 1 |
| Fiber optic connector | SC |
| Power over Ethernet (PoE) ports quantity | 1 |
Power
| Specification | Value |
|---|---|
| Input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (typical) | 24 W |
| Power over Ethernet (PoE) | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 158 mm |
| Depth | 133 mm |
| Height | 40 mm |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 5 - 90% |
Packaging data
| Specification | Value |
|---|---|
| Package width | 210 mm |
| Package depth | 87 mm |
| Package height | 260 mm |
| Package weight | 1.03 kg |
Certificates
| Specification | Value |
|---|---|
| Certification | FCC, CE |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | Taiwan |
