Intellinet Fast Ethernet WDM Bi-Directional Single Mode Media Converter, 10/100Base-Tx to 100Base-Fx (SC) Single-Mode, 20 km (12.4 mi.), WDM (Rx1310/Tx1550)

Intellinet Fast Ethernet WDM Bi-Directional Single Mode Media Converter, 10/100Base-Tx to 100Base-Fx (SC) Single-Mode, 20 km (12.4 mi.), WDM (Rx1310/Tx1550)

Model 510530EAN 766623510530

41 specifications
  • Speed100 Mbit/s
  • ConnectivityWired
  • Weight180 g
  • ColourBlack
  • Maximum transfer distance20000 m
  • InternalNo
See all specifications

Overview

Speed
100 Mbit/s
Connectivity
Wired
Weight
180 g
Colour
Black
Maximum transfer distance
20000 m
Internal
No
Brand
Intellinet
Model
510530
Part number
510530
EAN / UPC
766623510530
Also known as
Intellinet Fast Ethernet WDM Bi-Directional Single Mode Media Converter, 10/100Base-Tx to 100Base-Fx (SC) Single-Mode, 20 km (12.4 mi.), WDM (Rx1310/Tx1550)

Specifications

41 specifications in 10 groups

Network

Maximum data transfer rate100 Mbit/s
Converter input interface10Base-T, 100Base-TX
Converter output interface100Base-FX
Networking standardsIEEE 802.3, IEEE 802.3u
Ethernet interface typeFast Ethernet
Ethernet LAN data rates10,100 Mbit/s
Copper ethernet cabling technology10BASE-T, 100BASE-TX
Fiber ethernet cabling technology100BASE-FX
Duplex systemFull
Cable types supportedCat5e

Performance

Maximum transfer distance20000 m
Wavelength-division multiplexing (WDM)Yes
Fiber mode structureSingle-mode
Fiber cable diameters supported (core/cladding)9/125 µm
Tx power (min)-15 dBmW
Tx power (max)-3 dBmW
Sensitivity-32 dBmW
Mean time between failures (MTBF)100000 h

Features

InternalNo
Housing materialMetal
LED indicatorsYes
Product colourBlack

Ports & interfaces

Connectivity technologyWired
Ethernet LAN (RJ-45) ports1
Fiber ports quantity1
Fiber optic connectorSC
DC-in jackYes

Power

Output current1.2 A
Power consumption (max)2.5 W
External power adapterYes

Weight & dimensions

Width69 mm
Depth105 mm
Height25 mm
Weight180 g

Operational conditions

Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-20 - 70 °C
Operating relative humidity (H-H)10 - 80%

Packaging content

AC adapter includedYes
ManualYes

Certificates

CertificationFCC Class A, CE

Logistics data

Harmonized System (HS) code85176990
