Intellinet Fast Ethernet Single Mode Media Converter, 10/100Base-Tx to 100Base-Fx (SC) Single-Mode, 20km
Model 507332EAN 766623507332
32 specifications
- Speed100 Mbit/s
- Weight180 g
- Maximum transfer distance20000 m
- InternalNo
- Fiber optic connectorSC
- Input voltage5 V
Overview
- Speed
- 100 Mbit/s
- Weight
- 180 g
- Maximum transfer distance
- 20000 m
- Internal
- No
- Fiber optic connector
- SC
- Input voltage
- 5 V
- Brand
- Intellinet
- Category
- Network Media Converter
- Model
- 507332
- Part number
- 507332
- EAN / UPC
- 766623507332
- Also known as
- Intellinet Fast Ethernet Single Mode Media Converter, 10/100Base-Tx to 100Base-Fx (SC) Single-Mode, 20km
Specifications
32 specifications in 10 groups
Network
| Specification | Value |
|---|---|
| Maximum data transfer rate | 100 Mbit/s |
| Converter input interface | 100BASE-FX, 100Base-TX |
| Converter output interface | 100Base-FX |
| Networking standards | IEEE 802.3, IEEE 802.3u |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Auto MDI/MDI-X | Yes |
| Duplex system | Full |
Performance
| Specification | Value |
|---|---|
| Maximum transfer distance | 20000 m |
| Wavelength | 1310 nm |
| Fiber mode structure | Single-mode |
| Sensitivity | -32 dBmW |
| Mean time between failures (MTBF) | 100000 h |
Features
| Specification | Value |
|---|---|
| Internal | No |
| Housing material | Metal |
| LED indicators | Activity, Link, Power |
Ports & interfaces
| Specification | Value |
|---|---|
| Fiber optic connector | SC |
Power
| Specification | Value |
|---|---|
| Input voltage | 5 V |
| Input current | 1 A |
| Power consumption (max) | 5 W |
| External power adapter | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 70 mm |
| Depth | 105 mm |
| Height | 26 mm |
| Weight | 180 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -45 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Manual | Yes |
Certificates
| Specification | Value |
|---|---|
| Certification | FCC B, CE |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
