DMC-810SC network media converter 2000 Mbit/s 1310 nm Black
Model DMC-810SCPart no. DMC-810SC/EEAN 790069241727
52 specifications
- Speed2000 Mbit/s
- ConnectivityWired
- Weight302 g
- ColourBlack
- Maximum transfer distance20000 m
- InternalNo
Overview
- Speed
- 2000 Mbit/s
- Connectivity
- Wired
- Weight
- 302 g
- Colour
- Black
- Maximum transfer distance
- 20000 m
- Internal
- No
- Brand
- D-Link
- Category
- Network Media Converter
- Model
- DMC-810SC
- Part number
- DMC-810SC/E
- EAN / UPC
- 790069241727, 790069241703, 790069241710, 790069241734 +1 more
- Also known as
- D-Link DMC-810SC network media converter 2000 Mbit/s 1310 nm Black
Specifications
52 specifications in 11 groups
Network
| Specification | Value |
|---|---|
| Maximum data transfer rate | 2000 Mbit/s |
| Converter input interface | 1000Base-T |
| Converter output interface | 1000Base-LX, 1000Base-SX |
| Networking standards | IEEE 802.3ab, IEEE 802.3z |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 1000 Mbit/s |
| Fiber ethernet cabling technology | 1000BASE‑LX, 1000BASE‑SX |
| Auto MDI/MDI-X | Yes |
| Store-and-forward | Yes |
| Duplex system | Full |
| Cabling technology | RJ-45 |
Performance
| Specification | Value |
|---|---|
| Maximum transfer distance | 20000 m |
| Wavelength | 1310 nm |
Features
| Specification | Value |
|---|---|
| Internal | No |
| LED indicators | Yes |
| Product colour | Black |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Ethernet LAN (RJ-45) ports | 1 |
| Fiber optic connector | SC |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| Input voltage | 5 V |
| Input current | 1 A |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 120 mm |
| Depth | 88 mm |
| Height | 25 mm |
| Weight | 302 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -25 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
Packaging data
| Specification | Value |
|---|---|
| Package width | 208 mm |
| Package depth | 274 mm |
| Package height | 68 mm |
| Package weight | 772.4 g |
Certificates
| Specification | Value |
|---|---|
| Certification | FCC Class A CE Class A VCCI Class A |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
| Master (outer) cases per pallet (air) | 33 pc(s) |
| Master (outer) cases per pallet (sea) | 44 pc(s) |
| Pallet gross length | 110 cm |
| Pallet gross weight (air) | 297.5 kg |
| Pallet gross weight (sea) | 390.7 kg |
| Pallet gross width | 120 cm |
| Pallet height (air) | 149.1 cm |
| Pallet height (sea) | 194.3 cm |
| Products per pallet (air) | 330 pc(s) |
| Products per pallet (sea) | 440 pc(s) |
| Products per shipping (inner) case | 10 pc(s) |
| Shipping (inner) case gross weight | 8.43 kg |
| Shipping (inner) case height | 45.2 cm |
| Shipping (inner) case length | 37 cm |
| Shipping (inner) case net weight | 6.98 kg |
| Shipping (inner) case width | 29.1 cm |
Other features
| Specification | Value |
|---|---|
| I/O ports | 1000BASE-T, 1000BASE-SX/LX, MDI-II/MDI-X |
