MC100SA-20 network media converter 100 Mbit/s 1310 nm Single-mode Black
Model MC100SA-20EAN 6971690790479
22 specifications
- Speed100 Mbit/s
- ConnectivityWired
- ColourBlack
- Maximum transfer distance20000 m
- InternalNo
- Input voltage100 - 240 V
Overview
- Speed
- 100 Mbit/s
- Connectivity
- Wired
- Colour
- Black
- Maximum transfer distance
- 20000 m
- Internal
- No
- Input voltage
- 100 - 240 V
- Brand
- Cudy
- Category
- Network Media Converter
- Model
- MC100SA-20
- Part number
- MC100SA-20
- EAN / UPC
- 6971690790479
- Also known as
- Cudy MC100SA-20 network media converter 100 Mbit/s 1310 nm Single-mode Black
Specifications
22 specifications in 6 groups
Network
| Specification | Value |
|---|---|
| Maximum data transfer rate | 100 Mbit/s |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Jumbo frames support | Yes |
| Jumbo frames | 9 |
Performance
| Specification | Value |
|---|---|
| Maximum transfer distance | 20000 m |
| Wavelength | 1310 nm |
| Fiber mode structure | Single-mode |
| Buffer size | 9 KB |
| Mean time between failures (MTBF) | 50000 h |
Features
| Specification | Value |
|---|---|
| Internal | No |
| Plug and Play | Yes |
| LED indicators | Yes |
| Product colour | Black |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Ethernet LAN (RJ-45) ports | 1 |
| Fiber ports quantity | 1 |
| Fiber optic connector | SC |
Power
| Specification | Value |
|---|---|
| Input voltage | 100 - 240 V |
| Output voltage | 5 V |
| Power consumption (typical) | 3 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -45 - 80 °C |
