Fast Ethernet multimode fiber uplink, (SC)
Model Fast Ethernet multimode fiber uplink, (SC)Part no. AT-A40/SC
15 specifications
- Speed100 Mbit/s
- ConnectivityWired
- Maximum transfer distance2000 m
- Hot-swapYes
- Operating temperature (T-T)0 - 40 °C
Overview
- Speed
- 100 Mbit/s
- Connectivity
- Wired
- Maximum transfer distance
- 2000 m
- Hot-swap
- Yes
- Operating temperature (T-T)
- 0 - 40 °C
- Brand
- Allied Telesis
- Category
- Network Media Converter
- Model
- Fast Ethernet multimode fiber uplink, (SC)
- Part number
- AT-A40/SC
- Also known as
- Allied Telesis Fast Ethernet multimode fiber uplink, (SC) network media converter 100 Mbit/s 1310 nm
Specifications
15 specifications in 7 groups
Network
| Specification | Value |
|---|---|
| Maximum data transfer rate | 100 Mbit/s |
| Cabling technology | 100FX |
Performance
| Specification | Value |
|---|---|
| Maximum transfer distance | 2000 m |
| Wavelength | 1310 nm |
Features
| Specification | Value |
|---|---|
| Hot-swap | Yes |
| LED indicators | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -25 - 70 °C |
| Operating relative humidity (H-H) | 5 - 95% |
Certificates
| Specification | Value |
|---|---|
| Safety | UL, cUL, TUV |
| Certification | EN55024 UL 60950, CAN/CSA-C22.2 NO. 60950-00, EN60950 |
Other features
| Specification | Value |
|---|---|
| Data link protocols | Fast Ethernet |
| Connector(s) | SC |
| Electromagnetic emissions | EN55022 class A, FCC class A, VCCI class A |
