AT-MC116XL network media converter 100 Mbit/s 850 nm
Model AT-MC116XLPart no. AT-MC116XL-60EAN 7670351926736
11 specifications
- Speed100 Mbit/s
- ConnectivityWired
- Wavelength850 nm
- Power consumption (typical)6 W
- Operating temperature (T-T)0 - 50 °C
Overview
- Speed
- 100 Mbit/s
- Connectivity
- Wired
- Wavelength
- 850 nm
- Power consumption (typical)
- 6 W
- Operating temperature (T-T)
- 0 - 50 °C
- Brand
- Allied Telesis
- Category
- Network Media Converter
- Model
- AT-MC116XL
- Part numbers
- AT-MC116XL-60, AT-MC116XL-30, AT-MC116XL-10
- EAN / UPC
- 7670351926736, 767035151458, 767035151465, 7670351514650 +1 more
- Also known as
- Allied Telesis AT-MC116XL network media converter 100 Mbit/s 850 nm
Specifications
11 specifications in 7 groups
Network
| Specification | Value |
|---|---|
| Maximum data transfer rate | 100 Mbit/s |
Performance
| Specification | Value |
|---|---|
| Wavelength | 850 nm |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 6 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 80 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating altitude | 0 - 3000 m |
Certificates
| Specification | Value |
|---|---|
| Safety | UL-Cul, CSA/CSA, NRTL, TUV, CE |
| Certification | FCC Class A, FCC Class B |
Other features
| Specification | Value |
|---|---|
| Power requirements | 240V AC, 50Hz |
