Allied Telesis AT-FS232/1 network media converter 100 Mbit/s
Model AT-FS232/1Part no. AT-FS232/1-10EAN 767035154367
17 specifications
- Speed100 Mbit/s
- ConnectivityWired
- Maximum transfer distance15000 m
- LED indicatorsYes
- Power consumption (typical)6 W
- Operating temperature (T-T)0 - 40 °C
Overview
- Speed
- 100 Mbit/s
- Connectivity
- Wired
- Maximum transfer distance
- 15000 m
- LED indicators
- Yes
- Power consumption (typical)
- 6 W
- Operating temperature (T-T)
- 0 - 40 °C
- Brand
- Allied Telesis
- Category
- Network Media Converter
- Model
- AT-FS232/1
- Part numbers
- AT-FS232/1-10, AT-FS232/1-60, AT-FS232/1-20, AT-FS232/1-30
- EAN / UPC
- 767035154367, 767035192697, 5052217065421
- Also known as
- Allied Telesis AT-FS232/1 network media converter 100 Mbit/s
Specifications
17 specifications in 8 groups
Network
| Specification | Value |
|---|---|
| Maximum data transfer rate | 100 Mbit/s |
Performance
| Specification | Value |
|---|---|
| Maximum transfer distance | 15000 m |
Features
| Specification | Value |
|---|---|
| LED indicators | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 6 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 80 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating altitude | 0 - 3048 m |
Certificates
| Specification | Value |
|---|---|
| Safety | UL-Cul, CSA/CSA, NRTL, TUV, CE |
Other features
| Specification | Value |
|---|---|
| Data link protocols | Fast Ethernet |
| Connector(s) | SC |
| Dimensions (WxDxH) | 105 x 95 x 25 mm |
| Full duplex | Yes |
| Packet transfer speed | 14880/148800 pps |
| Power requirements | 100-240VAC@50/60Hz; 12VDC +/- 5%; 0.5A |
| Electromagnetic emissions | FCC Class A |
