XGN100C Internal Ethernet 1000 Mbit/s
Model XGN100CPart no. XGN100C-ZZ0101FEAN 760559127312
33 specifications
- Speed1000 Mbit/s
- ConnectivityWired
- Weight78 g
- InternalYes
- Operating temperature (T-T)0 - 40 °C
- Width82 mm
Overview
- Speed
- 1000 Mbit/s
- Connectivity
- Wired
- Weight
- 78 g
- Internal
- Yes
- Operating temperature (T-T)
- 0 - 40 °C
- Width
- 82 mm
- Brand
- Zyxel
- Category
- Network Card
- Model
- XGN100C
- Part number
- XGN100C-ZZ0101F
- EAN / UPC
- 760559127312, 4718937613137
- Also known as
- Zyxel XGN100C Internal Ethernet 1000 Mbit/s
Specifications
33 specifications in 10 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Host interface | PCI Express |
| Interface | Ethernet |
| Ethernet LAN (RJ-45) ports | 1 |
Network
| Specification | Value |
|---|---|
| Maximum data transfer rate | 1000 Mbit/s |
| Networking standards | IEEE 802.1p, IEEE 802.3ab, IEEE 802.3an, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u |
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
Design
| Specification | Value |
|---|---|
| Internal | Yes |
| Component for | PC |
| LED indicators | Yes |
| Country of origin | China |
| Certification | CE, FCC, EAC, BSMI |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Server operating systems supported | Windows Server 2012 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Storage relative humidity (H-H) | 0 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 82 mm |
| Depth | 68 mm |
| Height | 18 mm |
| Weight | 78 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 170 mm |
| Package depth | 137 mm |
| Package height | 30 mm |
| Package weight | 178 g |
Packaging content
| Specification | Value |
|---|---|
| Mounting brackets included | Yes |
| Quick installation guide | Yes |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | CE, REACH |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
