3-Port PCI Express USB 3.0 Card + Gigabit Ethernet - 5Gbps - TAA
Model PEXUSB3S3GEEAN 065030860796
53 specifications
- Speed5000 Mbit/s
- ConnectivityWired
- Weight60 g
- ColourMetallic, Red
- InternalYes
- Operating temperature (T-T)5 - 50 °C
Overview
- Speed
- 5000 Mbit/s
- Connectivity
- Wired
- Weight
- 60 g
- Colour
- Metallic, Red
- Internal
- Yes
- Operating temperature (T-T)
- 5 - 50 °C
- Brand
- StarTech.com
- Category
- Network Card
- Model
- PEXUSB3S3GE
- Part number
- PEXUSB3S3GE
- EAN / UPC
- 065030860796, 4058829151881
- Also known as
- StarTech.com 3-Port PCI Express USB 3.0 Card + Gigabit Ethernet - 5Gbps - TAA
Specifications
53 specifications in 11 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Host interface | PCI Express |
| Interface | Ethernet |
| Ethernet LAN (RJ-45) ports | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity | 3 |
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
| PCI version | 2.0 |
| PCI Card form factor | Full-height (low-profile) |
Network
| Specification | Value |
|---|---|
| Maximum data transfer rate | 5000 Mbit/s |
| Networking standards | IEEE 802.1p, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Cabling technology | 10/100/1000BaseT(X) |
| Wake-on-LAN ready | Yes |
| Auto MDIX IEEE | Yes |
| Full duplex | Yes |
| Auto-negotiation | Yes |
| Jumbo frames | 9000 |
| Jumbo frames support | Yes |
| VLAN tagging | Yes |
Design
| Specification | Value |
|---|---|
| Internal | Yes |
| Product colour | Metallic, Red |
| Chipset | Renesas / NEC - µPD720201, Realtek - RTL8153 |
| LED indicators | Activity, Link |
| Mean time between failures (MTBF) | 1920042 h |
| Certification | CE, FCC |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows |
| Linux operating systems supported | Yes |
| Server operating systems supported | Windows Server 2008 R2, Windows Server 2012 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 50 °C |
| Storage temperature (T-T) | -25 - 70 °C |
| Operating relative humidity (H-H) | 20 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 18 mm |
| Depth | 77 mm |
| Height | 120 mm |
| Weight | 60 g |
Packaging data
| Specification | Value |
|---|---|
| Drivers included | Yes |
| Quantity per pack | 1 pc(s) |
| Package width | 143 mm |
| Package depth | 174 mm |
| Package height | 33 mm |
| Package weight | 150 g |
Packaging content
| Specification | Value |
|---|---|
| Mounting brackets included | Yes |
| Manual | Yes |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
| Master (outer) case width | 378 mm |
| Master (outer) case length | 496 mm |
| Master (outer) case height | 320 mm |
| Products per master (outer) case | 60 pc(s) |
Other features
| Specification | Value |
|---|---|
| Flow control support | Yes |
| UASP support | Yes |
| USB data transfer rates | 5000 Mbit/s |
