UE305 network card Ethernet 1000 Mbit/s
Model UE305EAN 840030701528
34 specifications
- Speed1000 Mbit/s
- ConnectivityWired
- Weight20 g
- ColourBlack
- InternalNo
- USB poweredYes
Overview
- Speed
- 1000 Mbit/s
- Connectivity
- Wired
- Weight
- 20 g
- Colour
- Black
- Internal
- No
- USB powered
- Yes
- Brand
- TP-Link
- Category
- Network Card
- Model
- UE305
- Part number
- UE305
- EAN / UPC
- 840030701528, 6935364072612
- Also known as
- TP-Link UE305 network card Ethernet 1000 Mbit/s
Specifications
34 specifications in 11 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Host interface | USB |
| Interface | Ethernet |
| Ethernet LAN (RJ-45) ports | 1 |
| USB connector form factor | Straight |
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
Network
| Specification | Value |
|---|---|
| Maximum data transfer rate | 1000 Mbit/s |
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
Design
| Specification | Value |
|---|---|
| Internal | No |
| Component for | PC/Laptop |
| Product colour | Black |
| Chipset | ASIX AX88179 |
| Plug and Play | Yes |
| LED indicators | Status |
| Certification | CE, FCC, RoHS |
Power
| Specification | Value |
|---|---|
| USB powered | Yes |
System requirements
| Specification | Value |
|---|---|
| Compatible operating systems | Nintendo Switch, Windows 10/8.1/8/7, Mac OS X 10.9 and later versions, Linux(Ubuntu) |
| Windows operating systems supported | Windows 8.1, Windows 10, Windows 11, Windows 7 |
| Mac operating systems supported | MacOS |
| Linux operating systems supported | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 71 mm |
| Depth | 26 mm |
| Height | 16.2 mm |
| Weight | 20 g |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
Packaging content
| Specification | Value |
|---|---|
| Quick installation guide | Yes |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | CE, Federal Communications Commission (FCC), RoHS |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84733020 |
