TP-Link TL-WN823N(EN) network card WLAN 300 Mbit/s

TL-WN823N(EN) network card WLAN 300 Mbit/s

Model TL-WN823N(EN)

43 specifications

Speed300 Mbit/s
ConnectivityWireless
ColourBlack
InternalNo
USB poweredYes
Operating temperature (T-T)0 - 40 °C

See all specifications

Overview

Speed: 300 Mbit/s
Connectivity: Wireless
Colour: Black
Internal: No
USB powered: Yes
Operating temperature (T-T): 0 - 40 °C

Brand: TP-Link
Category: Network Card
Model: TL-WN823N(EN)
Part number: TL-WN823N(EN)
Also known as: TP-Link TL-WN823N(EN) network card WLAN 300 Mbit/s

Specifications

43 specifications in 12 groups

Ports & interfaces

Specification	Value
Connectivity technology	Wireless
Host interface	USB
Interface	WLAN

Network

Specification	Value
Maximum data transfer rate	300 Mbit/s
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Wi-Fi	Yes
Wi-Fi band	Single-band (2.4 GHz)
Frequency range	2.4 - 2.4835 GHz
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
WLAN data transfer rates supported	11,54,300 Mbit/s
Modulation	16-QAM, 64-QAM, CCK, DBPSK, DQPSK, OFDM
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Wake-on-LAN ready	Yes

Design

Specification	Value
Internal	No
Component for	PC/Laptop
Product colour	Black
Antenna	Yes
Antenna design	Internal
Transmitting power (CE)	20 dBm
Transmitting power (FCC)	20 dBm
Plug and Play	Yes
LED indicators	Status
Operating modes	Infrastructure mode

Power

Specification	Value
USB powered	Yes

System requirements

Specification	Value
Windows operating systems supported	Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Win
Mac operating systems supported	Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	5 - 90%

Sustainability

Specification	Value
Sustainability compliance	Yes

Weight & dimensions

Specification	Value
Width	39 mm
Depth	18.4 mm
Height	7.87 mm

Packaging data

Specification	Value
Package width	138 mm
Package depth	128 mm
Package height	30 mm
Package weight	80 g

Packaging content

Specification	Value
Resource CD	Yes
Quick installation guide	Yes

Technical details

Specification	Value
Compliance certificates	CE, Federal Communications Commission (FCC), RoHS

Logistics data

Specification	Value
Harmonized System (HS) code	85176990
