TP-Link TL-WN8200ND network card WLAN 300 Mbit/s
TP-Link

TL-WN8200ND network card WLAN 300 Mbit/s

Model TL-WN8200NDEAN 8459730507402

44 specifications
  • Speed300 Mbit/s
  • ConnectivityWireless
  • ColourBlack
  • InternalNo
  • Linux operating systems supportedYes
  • Operating temperature (T-T)0 - 40 °C
See all specifications

Overview

Speed
300 Mbit/s
Connectivity
Wireless
Colour
Black
Internal
No
Linux operating systems supported
Yes
Operating temperature (T-T)
0 - 40 °C
Brand
TP-Link
Category
Network Card
Model
TL-WN8200ND
Part number
TL-WN8200ND
EAN / UPC
8459730507402, 163120657995, 566562944836, 845973050740 +5 more
Also known as
TP-Link TL-WN8200ND network card WLAN 300 Mbit/s

Specifications

44 specifications in 11 groups

Ports & interfaces

Connectivity technologyWireless
Host interfaceUSB
InterfaceWLAN

Network

Maximum data transfer rate300 Mbit/s
Networking standardsIEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Wi-FiYes
Wi-Fi bandSingle-band (2.4 GHz)
Frequency range2.4 - 2.4835 GHz
Top Wi-Fi standardWi-Fi 4 (802.11n)
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
WLAN data transfer rates supported150,300 Mbit/s
Security algorithms128-bit WEP, 64-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK, WPS

Design

InternalNo
Product colourBlack
AntennaYes
Antenna designExternal
Antenna connector typeRP-SMA
Antenna direction typeOmni-directional
Antenna gain level (max)5 dBi
Transmitting power (CE)20 dBm
Transmitting power (FCC)27 dBm
WPS push buttonYes
LED indicatorsYes
Operating modesInfrastructure mode

System requirements

Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Wind
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.9 Mavericks
Linux operating systems supportedYes

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-40 - 70 °C
Operating relative humidity (H-H)10 - 90%
Storage relative humidity (H-H)5 - 90%

Sustainability

Sustainability complianceYes

Weight & dimensions

Width90.8 mm
Depth60.8 mm
Height24.5 mm

Packaging data

Package width200 mm
Package depth150 mm
Package height39 mm
Package weight250 g

Packaging content

Cables includedUSB
Resource CDYes
Quick installation guideYes

Technical details

Compliance certificatesCE, Federal Communications Commission (FCC), RoHS

Logistics data

Harmonized System (HS) code85176990
