TP-Link TL-WN781ND network card Internal WLAN 150 Mbit/s

TP-Link TL-WN781ND network card Internal WLAN 150 Mbit/s

Model TL-WN781NDEAN 6935364050511

38 specifications
  • Speed150 Mbit/s
  • ConnectivityWireless
  • ColourGreen
  • InternalYes
  • Operating temperature (T-T)0 - 40 °C
  • Width120.8 mm
See all specifications

Overview

Speed
150 Mbit/s
Connectivity
Wireless
Colour
Green
Internal
Yes
Operating temperature (T-T)
0 - 40 °C
Width
120.8 mm
Brand
TP-Link
Category
Network Card
Model
TL-WN781ND
Part number
TL-WN781ND
EAN / UPC
6935364050511, 021111376242, 031112036175, 151904929246 +9 more
Also known as
TP-Link TL-WN781ND network card Internal WLAN 150 Mbit/s

Specifications

38 specifications in 11 groups

Ports & interfaces

Connectivity technologyWireless
Host interfacePCI Express
InterfaceWLAN

Network

Maximum data transfer rate150 Mbit/s
Networking standardsIEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Wi-FiYes
Wi-Fi bandSingle-band (2.4 GHz)
Frequency range2.4 - 2.4835 GHz
Wi-Fi standards802.11b, 802.11g
WLAN data transfer rates supported11,54,150 Mbit/s
Modulation16-QAM, 64-QAM, CCK, DBPSK, DQPSK, OFDM
Security algorithms128-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK

Design

InternalYes
Product colourGreen
AntennaYes
Antenna designExternal
Antenna direction typeOmni-directional
Antenna gain level (max)2 dBi
ChipsetAtheros
Operating modesInfrastructure mode

System requirements

Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterpris
Linux operating systems supportedYes

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-40 - 70 °C
Operating relative humidity (H-H)10 - 90%
Storage relative humidity (H-H)5 - 90%

Sustainability

Sustainability complianceYes

Weight & dimensions

Width120.8 mm
Depth78.5 mm
Height21.5 mm

Packaging data

Package width200 mm
Package depth150 mm
Package height39 mm
Package weight150 g

Packaging content

Resource CDYes
Quick installation guideYes

Technical details

Compliance certificatesRoHS, Federal Communications Commission (FCC), CE

Logistics data

Harmonized System (HS) code85176990
