TP-Link Archer T2U Nano

TP-Link Archer T2U Nano

Model Archer T2U NanoPart no. ARCHER T2U NANO V1EAN 840030700019

41 specifications

Speed433 Mbit/s
ConnectivityWireless
ColourBlack
InternalNo
USB poweredYes
Mac operating systems supportedmacOS

See all specifications

Overview

Speed: 433 Mbit/s
Connectivity: Wireless
Colour: Black
Internal: No
USB powered: Yes
Mac operating systems supported: macOS

Brand: TP-Link
Category: Network Card
Model: Archer T2U Nano
Part numbers: ARCHER T2U NANO V1, ARCHER T2U NANO
EAN / UPC: 840030700019, 6935364082635, 6935364099978
Also known as: TP-Link AC600 Nano Wireless USB WiFi Adapter

Specifications

41 specifications in 11 groups

Ports & interfaces

Specification	Value
Connectivity technology	Wireless
Host interface	USB
USB version	2.0

Network

Specification	Value
Maximum data transfer rate	433 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x
Wi-Fi	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Frequency range	2.4 - 5 GHz
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
WLAN data transfer rates supported	11,54,150,200,433 Mbit/s
Modulation	16-QAM, 64-QAM, 256-QAM, CCK, COFDM, DBPSK, DQPSK, OFDM
Security algorithms	64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
Bandwidth (first)	2.4 GHz
Bandwidth (second)	5 GHz

Design

Specification	Value
Internal	No
Product colour	Black
Antenna	Yes
Antenna design	Internal
Antenna direction type	Omni-directional
Receiver sensitivity	5GHz： 11a 6Mbps: -90dBm 11a 54Mbps: -73dBm 11n HT20 MCS0: -89dBm 11n HT20 MCS7: -70dBm 11n HT40 MCS0: -86dBm 11n HT40 MCS7: -67dBm 11ac VHT80 MCS0: -82dBm 11ac VHT80 MCS9: -56dBm 2.4GHz: 11b 1Mbps: -96dBm 11b 11Mbps: -88dBm 11g 6Mbps: -89dBm 11g 54Mbps: -74dBm 11n HT20 MCS0: -89dBm 11n HT20 MCS7: -7
Certification	CE, FCC

Power

Specification	Value
USB powered	Yes

System requirements

Specification	Value
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1, Windows XP
Mac operating systems supported	macOS
Linux operating systems supported	Yes

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	5 - 90%

Weight & dimensions

Specification	Value
Width	15 mm
Depth	7.1 mm
Height	18.6 mm

Packaging data

Specification	Value
Quantity per pack	1 pc(s)
Package width	138 mm
Package depth	128 mm
Package height	30 mm
Package weight	90 g

Packaging content

Specification	Value
Quick installation guide	Yes

Technical details

Specification	Value
Compliance certificates	RoHS

Other features

Specification	Value
Transmit power range	20 - 20 dBmW
