StarTech.com 5G PCIe Network Adapter Card - NBASE-T & 5GBASE-T 2.5BASE-T PCI Express Network Interface Adapter - 5GbE/2.5GbE/1GbE Multi Gigabit Ethernet Worksta

StarTech.com 5G PCIe Network Adapter Card - NBASE-T & 5GBASE-T 2.5BASE-T PCI Express Network Interface Adapter - 5GbE/2.5GbE/1GbE Multi Gigabit Ethernet Worksta

Model ST5GPEXNBEAN 065030879194

45 specifications
  • Speed5000 Mbit/s
  • ConnectivityWired
  • Weight138 g
  • ColourBlack
  • InternalYes
  • Operating temperature (T-T)0 - 70 °C
See all specifications

Overview

Speed
5000 Mbit/s
Connectivity
Wired
Weight
138 g
Colour
Black
Internal
Yes
Operating temperature (T-T)
0 - 70 °C
Brand
StarTech.com
Category
Network Card
Model
ST5GPEXNB
Part number
ST5GPEXNB
EAN / UPC
065030879194, 818239521483
Also known as
StarTech.com 5G PCIe Network Adapter Card - NBASE-T & 5GBASE-T 2.5BASE-T PCI Express Network Interface Adapter - 5GbE/2.5GbE/1GbE Multi Gigabit Ethernet Worksta

Specifications

45 specifications in 10 groups

Ports & interfaces

Connectivity technologyWired
Host interfacePCI Express
InterfaceEthernet
Ethernet LAN (RJ-45) ports1
PCI version2.0

Network

Maximum data transfer rate5000 Mbit/s
Networking standardsIEEE 802.1Q, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3bz, IEEE 802.3u
Ethernet LANYes
Ethernet interface typeGigabit Ethernet
Ethernet LAN data rates10,100,1000,2500,5000 Mbit/s
Copper ethernet cabling technology100BASE-TX, 1000BASE-T
Auto MDIX IEEEYes
Full duplexYes
Auto-negotiationYes
Jumbo frames9000
Jumbo frames supportYes
VLAN taggingYes

Design

InternalYes
Product colourBlack
ChipsetTehuti - TN4010, Marvell - 88E2010P
LED indicatorsActivity, Link
CertificationCE, FCC

System requirements

Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7
Mac operating systems supportedMac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave
Linux operating systems supportedYes
Server operating systems supportedWindows Server 2008 R2, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019

Operational conditions

Operating temperature (T-T)0 - 70 °C
Storage temperature (T-T)-40 - 85 °C
Operating relative humidity (H-H)10 - 90%

Weight & dimensions

Width120 mm
Depth80 mm
Height20 mm
Weight138 g

Packaging data

Drivers includedYes
Low-profile bracketYes
Package width142 mm
Package depth170 mm
Package height30 mm

Packaging content

ManualYes

Technical details

Compliance certificatesRoHS

Logistics data

Harmonized System (HS) code85176990
Master (outer) case width310 mm
Master (outer) case length590 mm
Master (outer) case height360 mm
Products per master (outer) case80 pc(s)
